Aten USB-PS/2 KVM Adapter Module with Local Console
|
|
Regularly: $371.00
On Sale: $356.16
Sale Ends:
April 26th, 2024
Manufacturer:
Aten
USB-PS/2 KVM Adapter Module with Local Console
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
38961929
|
KA7171
|
4710423778924 |
Active
|
Details
|
General Information |
|
Summary |
For smooth operation and added convenience, ATEN´s KA7171 USB-PS/2 KVM Adapter Module is designed to provide a full console connection locally in a KVM over IP Switch or Matrix KVM* installation. The KA7171 allows a PS/2 or USB server to be connected to the switch via Cat 5e/6 cable and provides an extra console via USB keyboard, USB mouse, and monitor to use for extended local operations. In addition, the Privileged Console Control function prevents remote users from operating the device when a local administrator requires full control of the server - reducing conflicts and unwanted operations. |
|
Ports & interfaces |
|
Keyboard port type |
USB |
|
Mouse port type |
USB |
|
Video port type |
VGA |
|
Audio connections |
No |
|
Console port |
SPHD-18 |
|
DC-in jack |
Yes |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Performance |
|
Maximum resolution |
1920 x 1200 pixels |
|
Design |
|
Product colour |
Black |
|
Housing material |
Metal |
|
Certification |
CN ZL 01124239.6 , CN ZL 200410031689.0 , CN ZL 200410042772.8 , CN ZL 200710181531.5 , DE 102004019107 , DE 102004058233 , JP 4160936 , JP 5244448 , TW 150098 , TW I237762 , TW I243890 , TW I339467 , US 6160543 , US 6489854 , US 7532998 , US 7585176 , US 7613854 , US 8090553 |
|
Display |
|
Built-in display |
No |
|
Power |
|
AC input voltage |
5 V |
|
Power consumption (typical) |
3 W |
|
External power adapter |
No |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 80% |
|
Weight & dimensions |
|
Width |
865 mm |
|
Depth |
127 mm |
|
Height |
25 mm |
|
Weight |
330 g |
|
Packaging content |
|
Cables included |
KVM |
|
Manual |
Yes |
|
AC adapter included |
Yes |
|
