Aten USB DVI HDBaseT 2.0 KVM Extender
|
|
Regularly: $1063.00
On Sale: $1031.11
Sale Ends:
November 23rd, 2025
Manufacturer:
Aten
USB DVI HDBaseT™ 2.0 KVM Extender (Long Reach mode up to 1920 x 1080@150 m)
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
52570910
|
CE620
|
672792007170 |
Active
|
Details
|
General Information |
|
Summary |
The ATEN CE620 USB DVI HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to provide the most reliable transmission of video, audio, USB and RS-232 signals available on the market. Featured with a Long Reach mode, the CE620 delivers high-quality DVI video, PCM 2-channel digital audio, USB 2.0, and RS-232 signals up to 150 meters using a single Cat6/6a/ATEN 2L-2910 Cat 6 cable. With a simple cable installation supporting various signals, the CE620 is ideal for applications where convenient remote access is required – in places such as transportation control centers, medical facilities, industrial warehouses and extended workstations. |
|
Features |
|
Type |
Transmitter & receiver |
|
Connectivity technology |
Wired |
|
Maximum transfer distance |
100 m |
|
Cable types supported |
Cat5e, Cat6, Cat6a |
|
Product colour |
Black |
|
Material |
Metal |
|
Transmitter |
|
Transmitter local video port |
Yes |
|
Transmitter local video port type |
DVI-D |
|
Receiver |
|
Receiver local video port type |
DVI-D |
|
Power |
|
Power consumption (transmitter) (max) |
3 W |
|
Power consumption (receiver) (max) |
5.6 W |
|
Weight & dimensions |
|
Transmitter width |
18.2 cm |
|
Transmitter depth |
12.3 cm |
|
Transmitter height |
2.87 cm |
|
Transmitter weight |
630 g |
|
Receiver width |
18.2 cm |
|
Receiver depth |
12.3 cm |
|
Receiver height |
2.87 cm |
|
Receiver weight |
640 g |
|
Packaging content |
|
AC adapter included |
Yes |
|
Cables included |
DVI |
|
Manual |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 80% |
|
Other features |
|
Firmware upgradeable |
Yes |
|
