Aten 6 x 6 Dante Audio Interface with HDMI
|
|
Regularly: $1423.00
On Sale: $1380.31
Sale Ends:
December 7th, 2025
Manufacturer:
Aten
6 x 6 Dante Audio Interface with HDMI
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
55482533
|
VE66DTH
|
672792011573 |
Active
|
Details
|
General Information |
|
Summary |
ATEN VE66DTH is a Dante-enabled six−input/six−output Audio Interface with HDMI. Using Dante™ – the most popular audio networking solution created by Audinate, the VE66DTH is capable of delivering uncompressed, close-to-zero latency digital audio signals across your standard IP network. The VE66DTH transmits and receives up to 6-channel of audio inputs and outputs via a Dante network – the audio inputs can support not only the line input but also the dynamic and condenser microphones at the same time. Additionally, the device can also provide condenser microphones with 48V Phantom power supply. With its built-in PoE (Power over Ethernet), the VE66DTH can be powered by a compatible PSE device through Ethernet cable. Moreover, the VE66DTH provides flexible audio capability with audio de-embedding and embedding. It can de-embed HDMI stereo audio signals to the Dante networking system and embed Dante audio signals into the HDMI output.
The VE66DTH is tailor-made to a wide range of environments, such as conference centers, concert halls, entertainment facilities or wherever that requires implantation of Dante-based professional audio devices for extended and flexible networked AV applications. Users of the VE66DTH can benefit from improved system performance, reduction in cabling and more to installations of all sizes.
* Download Dante Controller |
|
Inputs |
|
Digital audio coaxial in |
0 |
|
Digital audio optical in |
0 |
|
HDMI in |
1 |
|
DC-in jack |
Yes |
|
USB 1.1 ports quantity |
0 |
|
Outputs |
|
Audio (L/R) out |
0 |
|
Number of HDMI outputs |
1 |
|
Technical details |
|
Product colour |
Black |
|
Maximum resolution |
4096 x 2160 pixels |
|
Housing material |
Metal |
|
Weight & dimensions |
|
Width |
154.9 mm |
|
Depth |
174.2 mm |
|
Height |
28.8 mm |
|
Weight |
850 g |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 80% |
|
Packaging data |
|
Quantity |
1 |
|
