Design |
|
Form factor |
Desktop |
|
Product colour |
Black |
|
Housing material |
Metal |
|
LED indicators |
Power |
|
Features |
|
Maximum resolution (VGA) |
1920 x 1080 pixels |
|
Maximum resolution (HDMI) |
4096 x 2160 pixels |
|
Supported graphics resolutions |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160 |
|
AirPlay mirroring |
Yes |
|
Google Cast |
Yes |
|
Number of simultaneously connected devices (max) |
2 |
|
Management features |
|
Web-based management |
Yes |
|
On/off switch |
Yes |
|
Antenna |
|
Antenna type |
External |
|
Antennas quantity |
2 |
|
Network |
|
Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
|
Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
|
Frequency band |
2.4/5 GHz |
|
Security algorithms |
WEP, WPA, WPA2, WPA2-PSK |
|
Maximum operating distance |
30 m |
|
Ports & interfaces |
|
Interface |
HDMI + VGA (D-Sub) |
|
Number of HDMI outputs |
1 |
|
VGA (D-Sub) output ports |
1 |
|
Ethernet LAN (RJ-45) ports |
1 |
|
USB 2.0 ports quantity |
1 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
|
Headphone outputs |
1 |
|
DC-in jack |
Yes |
|
Power |
|
Power source type |
DC |
|
Input voltage |
12 V |
|
Power consumption (typical) |
12 W |
|
Power over Ethernet (PoE) |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Operating relative humidity (H-H) |
-20 - 60% |
|
Storage temperature (T-T) |
0 - 80 °C |
|
Weight & dimensions |
|
Width |
104 mm |
|
Depth |
170 mm |
|
Height |
28.3 mm |
|
Weight |
470 g |
|
Package weight |
1.15 kg |
|
Packaging content |
|
AC adapter included |
Yes |
|
Quick start guide |
Yes |
|
Logistics data |
|
Country of origin |
Taiwan |
|
Products per master (outer) case |
5 pc(s) |
|
Master (outer) case gross weight |
6.37 kg |
|
Master (outer) case length |
500 mm |
|
Master (outer) case width |
232 mm |
|
Master (outer) case height |
283 mm |
