General Information |
|
Summary |
IW9167 11ax 6E AP 8 RF ports A domain Wi-Fi mode |
|
Features |
|
2.4 GHz |
Yes |
|
5 GHz |
Yes |
|
6 GHz |
Yes |
|
Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11d, IEEE 802.11h, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v |
|
MIMO |
Yes |
|
MIMO type |
Multi User MIMO |
|
Wi-Fi Multimedia (WMM)/(WME) |
Yes |
|
Maximal-Ratio Combining (MRC) |
Yes |
|
Cyclic Shift Diversity (CSD) |
Yes |
|
Dynamic Frequency Selection (DFS) |
Yes |
|
Security |
|
Security algorithms |
WPA, WPA2, WPA3 |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
1 |
|
SFP/SFP+ slots quantity |
1 |
|
DC-in jack |
Yes |
|
Power |
|
Power over Ethernet (PoE) |
Yes |
|
DC voltage range |
24 - 48 V |
|
Design |
|
Placement |
Ceiling, Wall |
|
Product colour |
White |
|
Performance |
|
Flash memory |
1024 MB |
|
Internal memory |
2048 MB |
|
Certificates |
|
Certification |
EN 60529 IP67
UL50E Type 4X
IEC 60068-2-1 (Cold)
IEC 60068-2-2 (Dry Heat)
IEC 60068-2-14 (Change of Temperature)
IEC 60068-2-30 (Damp Heat)
IEC 60068-2-6 (Vibration)
IEC 60068-2-27 (Shock)
IEC 60068-2-30 (Humidity)
IEC 60068-2-32 (Freefall)
IEC 60068-3-3 (Seismic)
FCC 47 CFR Part 15 Class A
EN 55032 Class A
VCCI Class A
AS/NZ CISPR 32 Class A
CISPR 32 Class A
ICES 003 Class A
CNS13438 Class A
EN 300 386
KS C 9832:2019
EN 301 489-1 v2.1.1
EN 301 489-17 v2.1.1
EN 301 489 – 19
EN 55035
CISPR35
KS C 9835:2019
KS X 3124
KS X 3126
IEC/EN 61000-4-2 - Electrostatic Discharge
IEC/EN 61000-4-3 - Radiated RF Immunity
IEC/EN 61000-4-5 - Surge
IEC/EN 61000-4-6 - Conducted RF Immunity
IEC/EN 61000-4-8 - Power Frequency Magnetic Field
IEC 61000-4-9 – Pulsed Magnetic Field
IEC 61000-4-11 - AC Voltage Dips
IEC 61000-4-18 - Damped Oscillatory Wave
EN-61000-4-29 - DC Voltage Dips
Class I Division 2 (C1D2)
UL/cUL C1D2
Zone 2/Zone 22 (ec+ic+tc)
UL 121201
CSA C22.2 No 213
ANSI/UL 60079-0, -7, -11, -31
IECEx
ATEX
UKEx
IEC/EN 60079-0
IEC/EN 60079-7
IEC/EN 60079-11
IEC/EN 60079-31 |
|
Weight & dimensions |
|
Width |
292 mm |
|
Depth |
267 mm |
|
Height |
71 mm |
|
Weight |
4.2 kg |
|
Packaging content |
|
Bundled software |
Cisco IOS ® XE Software Release 17.9.4 or later |
|
Operational conditions |
|
Operating relative humidity (H-H) |
0 - 100% |
|
Operating temperature (T-T) |
-40 - 70 °C |
|
Storage temperature (T-T) |
-40 - 85 °C |
|
Storage relative humidity (H-H) |
0 - 100% |
