Grandstream GWN7701P Layer 2 Unmanaged 4-port Poe Switch
|
|
Price: $62.00
Manufacturer:
Grandstream
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at; IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
59536260
|
GWN7701P
|
- |
Active
|
Details
|
General Information |
|
Summary |
The GWN7700 series are unmanaged network switches that provide a quick and cost-effective way to add high-speed Gigabit connectivity to home offices and small/medium businesses. It requires no configuration or installation, offers a desktop and wall-mountable design, and provides auto MDI/MDIX to eliminate the need for crossover cables. Each port supports auto-negotiation to allow the GWN7700 series to recognize the link speed of any 10/100/1000Mbps network device and intelligently adjust for compatibility and optimal performance. The PoE (Power-over-Ethernet) models provide ports with IEEE 802.3af/at compliant, smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points, and other PoE endpoints. The plug-and-play GWN7700 series are the ideal unmanaged network switches for home offices and small-to-medium businesses. |
|
Management features |
|
Switch type |
Unmanaged |
|
Quality of Service (QoS) support |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Installed SFP+ modules quantity |
1 |
|
Network |
|
Networking standards |
IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
|
10G support |
No |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Auto-negotiation |
Yes |
|
Active link detection |
Yes |
|
Data transmission |
|
Switching capacity |
16 Gbit/s |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9 |
|
Security |
|
IGMP snooping |
Yes |
|
Multicast features |
|
Multicast support |
Yes |
|
Design |
|
Product colour |
Black |
|
LED indicators |
Activity, Power |
|
Power |
|
Power source |
DC |
|
Power supply included |
Yes |
|
DC input voltage |
48 - 53.5 V |
|
Input current |
1.22 A |
|
Power consumption (max) |
3 W |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet (PoE) ports quantity |
4 |
|
Weight & dimensions |
|
Width |
100 mm |
|
Depth |
190 mm |
|
Height |
28 mm |
|
Weight |
440 g |
|
Packaging data |
|
Package width |
210 mm |
|
Package depth |
230 mm |
|
Package height |
51 mm |
|
Package weight |
920 g |
|
