HighPoint PCIe 4.0 X16 / 8X U.2 Raid Controller
|
|
Price: $1791.00
Manufacturer:
HighPoint
PCIe 4.0 x16 8-Port U.2 NVMe RAID HBA, Single RAID 0/1/10, 0.29 kg, 16.5 x 6.8 x 2.3 cm
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
57992054
|
SSD7580B
|
643653758036 |
Active
|
Details
|
General Information |
|
Summary |
The SSD7580B is the industry's most verstaile, high-performance PCIe Gen4 NVMe RAID HBA. The dedicated PCIe 4.0 x16 host interface and 8 independent device channels are capable of supporting over 100TB of hot-swappable NVMe storage, at speeds up to 28,000MB/s!
The compact, half-height form factor can be easily installed into nearly any industry standard PC-based server, workstation and rackmount platform running Windows and Linux based operating systems.
Like other members of the SSD7500 series product family, the SSD7580B is well equipped to tackle an extensive range of high-performance applications including AI training and analysis, high-speed data acquisition and security solutions, scientific modeling and imaging systems, 3D rendering and design, and HD media production and editing platforms.
Performance Focused Hardware Architecture
HighPoint’s unique performance-focused NVMe architecture utilizes intelligent switch technology to allocate up to x4 lanes of bandwidth to each NVMe device port. This enables the SSD7580B 8-port U.2 RAID controller to fully saturate x16 lanes of host bandwidth using as little as four NVMe SSDs.
However, additional SSDs can be added to maximize storage capacity, or fine tune the configuration for a specific application by optimizing a RAID array for sequential or random I/O.
Streamline Service Workflows with True Hot-Swap & Hot-Plug Capability
SSD7580B controllers combine the flexible serviceability of SAS/SATA solutions with the performance and reliability of enterprise U.2 storage. Integrated hot-plug and hot-swap support works exactly like you expect it to; it effectively eliminates the need to power down or reboot a system in order to add or remove NVMe SSDs.
The SSD7580’s true Hot-Plug and Hot-Swap capability enable administrators to add or remove one or more drives on the fly, as necessity demands. This includes RAID and single-drive configurations. The controller will notify the system of any changes in real time – no reboot required!
In addition, a wide selection of flexible cabling options is available for the SSD7580B, which enable the controller to host both RAID, non-RAID, and mixed configurations of U.2 or M.2 NVMe SSDs, via SFF8639, SFF-8643 and SFF-8611 backplanes. |
|
Ports & interfaces |
|
Supported storage drive interfaces |
M.2, U.2 |
|
Host interface |
PCI Express x16 |
|
PCI Express slots version |
4.0 |
|
Performance |
|
RAID levels |
0, 1, 10 |
|
Data transfer rate |
16 Gbit/s |
|
Form factor |
Low Profile PCIe |
|
SSD support |
Yes |
|
S.M.A.R.T. support |
Yes |
|
Mean time between failures (MTBF) |
920585 h |
|
Operational conditions |
|
Operating temperature (T-T) |
5 - 55 °C |
|
Storage temperature (T-T) |
-20 - 80 °C |
|
Weight & dimensions |
|
Width |
165 mm |
|
Depth |
23 mm |
|
Height |
68 mm |
|
Weight |
290 g |
|
