General Information |
|
Summary |
Built for small business users, the HL-L5000D delivers stunning results and high print speeds every time. The added benefit of optional high-yield toner cartridges makes this machine the ideal choice for your office. |
|
Printing |
|
Colour |
No |
|
Print technology |
Laser |
|
Duplex printing |
Yes |
|
Maximum resolution |
1200 x 1200 DPI |
|
Duplex printing mode |
Auto |
|
Duplex print speed (black, normal quality, A4/US Letter) |
20 ppm |
|
Warm-up time |
4.8 s |
|
Time to first page (black, normal) |
7.2 s |
|
N-up printing |
2, 4, 9, 16, 25 |
|
Economical printing |
Yes |
|
Features |
|
Maximum duty cycle |
50000 pages per month |
|
Printing colours |
Black |
|
Number of print cartridges |
1 |
|
Page description languages |
Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3 |
|
Recommended duty cycle |
0 - 3500 pages per month |
|
Country of origin |
Vietnam |
|
Input & output capacity |
|
Total number of input trays |
1 |
|
Total input capacity |
250 sheets |
|
Total output capacity |
150 sheets |
|
Paper input type |
Cassette, Paper tray |
|
Multi-Purpose tray |
Yes |
|
Multi-Purpose tray input capacity |
50 sheets |
|
Paper handling |
|
Maximum ISO A-series paper size |
A4 |
|
Paper tray media types |
Plain paper, Recycled paper, Thick paper, Thin paper |
|
ISO A-series sizes (A0...A9) |
A4, A5, A6 |
|
Multi-purpose tray media types |
Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper |
|
Non-ISO print media sizes |
Executive, Folio, Letter, Legal |
|
Custom media width |
76.2 - 215.9 mm |
|
Custom media length |
127 - 355.6 mm |
|
Paper tray media weight |
60 - 120 g/m² |
|
Multi-Purpose Tray media weight |
60 - 200 g/m² |
|
Duplex media weight |
60 - 120 g/m² |
|
Ports & interfaces |
|
USB port |
Yes |
|
Standard interfaces |
Parallel, USB 2.0 |
|
USB 2.0 ports quantity |
1 |
|
Network |
|
Wi-Fi |
No |
|
Ethernet LAN |
No |
|
Network ready |
No |
|
Mobile printing technologies |
Not supported |
|
Performance |
|
Built-in processor |
Yes |
|
Processor family |
ARM Cortex |
|
Processor frequency |
800 MHz |
|
Sound pressure level (printing) |
52 dB |
|
Sound pressure level (quiet mode) |
50 dB |
|
Sound power level (standby) |
34 dB |
|
Design |
|
Product colour |
Graphite |
|
Built-in display |
Yes |
|
Display |
LCD |
|
Display number of lines |
1 lines |
|
Power |
|
Power consumption (printing) |
640 W |
|
Power consumption (standby) |
32 W |
|
Power consumption (PowerSave) |
390 W |
|
Power consumption (off) |
0.04 W |
|
AC input frequency |
50 - 60 Hz |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 32 °C |
|
Storage temperature (T-T) |
0 - 40 °C |
|
Operating relative humidity (H-H) |
20 - 80% |
|
Storage relative humidity (H-H) |
35 - 85% |
|
Weight & dimensions |
|
Width |
443 mm |
|
Depth |
375 mm |
|
Height |
485 mm |
|
Weight |
11 kg |
|
Packaging data |
|
Package weight |
13.2 kg |
|
Packaging content |
|
Drivers included |
Yes |
|
Quick start guide |
Yes |
|
Logistics data |
|
Harmonized System (HS) code |
84433210 |
|
Pallet gross height |
16.5 cm |
|
Pallet gross weight |
226 kg |
|
Master (outer) cases per pallet |
16 pc(s) |
|
Layers per pallet |
4 pc(s) |
|
Products per pallet |
16 pc(s) |
|
Technical details |
|
Master (outer) cases per pallet layer |
4 pc(s) |
|
Pallet type |
1200 x 1000 mm |
|
Other features |
|
Spare part retention |
5 year(s) |
