General Information |
|
Summary |
Intel® Xeon® Processor Scalable Family, Single Socket P (LGA 3647) supported, CPU TDP support 205W
Intel® C622 chipset
Up to 1TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 8x DIMM slots
Expansion slots:
1 PCI-E 3.0 x16,
1 PCI-E 3.0 x16 (x16 || x8),
1 PCI-E 3.0 x8 (x0 || x8),
1 PCI-E 3.0 x8,
1 PCI-E 3.0 x4 (in x8)
2 10GbE LAN ports
10 SATA3 (6Gbps) via C622
I/O: 1 VGA, 2 COM, TPM header
2 SuperDOM with built-in power
5 USB 3.0 (2 rear, 1 Type-A, 2 via header), 6 USB 2.0 (2 rear, 4 via headers)
M.2 NGFF connector |
|
Processor |
|
Processor manufacturer |
Intel |
|
Processor thermal power (max) |
205 W |
|
Memory |
|
Supported memory types |
DDR4-SDRAM |
|
Maximum internal memory |
1 TB |
|
Memory voltage |
1.2 V |
|
ECC |
Yes |
|
Supported memory clock speeds |
1600,1866,2133,2400,2666 MHz |
|
Storage controllers |
|
RAID levels |
0, 5, 10 |
|
Internal I/O |
|
USB 2.0 connectors |
6 |
|
Rear panel I/O ports |
|
USB 2.0 ports quantity |
6 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
|
VGA (D-Sub) ports quantity |
1 |
|
COM ports quantity |
2 |
|
Network |
|
Wi-Fi |
No |
|
Ethernet LAN |
Yes |
|
Ethernet interface type |
10 Gigabit Ethernet |
|
Features |
|
Motherboard form factor |
ATX |
|
Expansion slots |
|
PCI Express x16 (Gen 3.x) slots |
1 |
|
BIOS |
|
BIOS type |
UEFI AMI |
|
ACPI version |
6.0 |
|
Processor special features |
|
Trusted Platform Module (TPM) |
Yes |
|
Operational conditions |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Operating relative humidity (H-H) |
8 - 90% |
|
Storage relative humidity (H-H) |
5 - 95% |
|
Logistics data |
|
Harmonized System (HS) code |
84733020 |
|
Weight & dimensions |
|
Width |
304.8 mm |
|
Depth |
243.8 mm |
|
Other features |
|
PCI Express x4 (Gen 3.x) slots |
1 |
|
PCI Express x8 (Gen 3.x) slots |
1 |
|
Supported DIMM module capacities |
4GB, 8GB, 16GB, 32GB, 64GB, 128MB |
|
Number of DIMM slots |
8 |
