General Information |
|
Summary |
Features:
- 8 x Gigabit ports
- 2 x shared SFP slots
- 16 Gbps switching capacity
- Built-in power supply
- Advanced Web Smart management
- Fanless design reduces energy consumption and operating noise
- Rackmount brackets included |
|
Management features |
|
Switch type |
Managed |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
MIB support |
MIB, MIB-II |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Gigabit Ethernet (copper) ports quantity |
8 |
|
Combo SFP ports quantity |
2 |
|
Network |
|
Networking standards |
IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z |
|
10G support |
No |
|
Copper ethernet cabling technology |
1000BASE-T, 100BASE-TX, 10BASE-T |
|
Port mirroring |
Yes |
|
Full duplex |
Yes |
|
Link aggregation |
Yes |
|
Spanning tree protocol |
Yes |
|
Head-of-line (HOL) blocking |
Yes |
|
VLAN support |
Yes |
|
Number of VLANs |
256 |
|
Data transmission |
|
MAC address table |
16000 entries |
|
Switching capacity |
16 Gbit/s |
|
Throughput |
11.9 Mpps |
|
Jumbo frames support |
Yes |
|
Security |
|
DHCP features |
DHCP server, DHCP client |
|
IGMP snooping |
Yes |
|
Security algorithms |
802.1x RADIUS, HTTPS |
|
Multicast features |
|
Multicast support |
Yes |
|
Protocols |
|
Management protocols |
HTTP/HTTPS (SSL v2/3 TLS), SNMP v1/v2c/v3 |
|
Design |
|
Rack mounting |
Yes |
|
Product colour |
Black |
|
LED indicators |
Yes |
|
Performance |
|
Compatible operating systems |
Windows 8.1, 8, 7, Vista, XP, Windows 2003/2008 Server |
|
Mean time between failures (MTBF) |
1054337 h |
|
Power |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50 - 60 Hz |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
No |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 45 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Weight & dimensions |
|
Width |
280 mm |
|
Depth |
180 mm |
|
Height |
44 mm |
|
Weight |
1.5 kg |
|
Certificates |
|
Certification |
CE, FCC |
