General Information |
|
Summary |
Show movies on a mammoth scale (up to 300 inches or 762 cm in size) in a billion colors and astonishing clarity. Make your living room your personal multiplex with Acer Home Series projectors, and leave behind the ordinary in entertainment for a cinematic experience that is truly awesome.
Auto Ceiling Mount Correction
This feature automatically flips the projected image over if the projector is turned upside down.
Ultra HD
3840x2160 resolution in a 16:9 aspect ratio gives you 4 times more detail than Full HD, for crystal-clear movies!
Lens Shift
Reposition and resize the projected image on the screen, without distortion, via a simple control system.
Acer EcoProjection
This device is designed to help the planet by automatically reducing standby power consumption by as much as 80%.
Acer DynamicBlack
Improves image contrast by dynamically adjusting dark scenes to optimal black levels.
Wireless Projection
Project content without bothersome cables. Say goodbye to cable clutter and manual connecting of devices. |
|
Projector |
|
Projector brightness |
2200 ANSI lumens |
|
Projection technology |
DLP |
|
Projector native resolution |
UHD 4K (3840x2160) |
|
Native aspect ratio |
16:9 |
|
Supported aspect ratios |
4:3, 16:9 |
|
Projection distance |
1.3 - 9.3 m |
|
Contrast ratio (dynamic) |
1200000:1 |
|
Number of colours |
1.073 billion colours |
|
Horizontal synchronization (min) |
15 kHz |
|
Horizontal synchronization (max) |
135 kHz |
|
Vertical synchronization (min) |
0.024 kHz |
|
Vertical synchronization (max) |
0.12 kHz |
|
Light source |
|
Light source type |
Lamp |
|
Service life of light source |
4000 h |
|
Service life of light source (economic mode) |
10000 h |
|
Lamp type |
UHP |
|
Lamp power |
240 W |
|
Lamps quantity |
1 lamp(s) |
|
Lens system |
|
Focus |
Manual |
|
Focal length range |
20.91 - 32.62 mm |
|
Aperture range (F-F) |
2.5 - 3.26 |
|
Digital zoom |
2x |
|
Optical zoom |
1.6x |
|
Ports & interfaces |
|
VGA (D-Sub) ports quantity |
2 |
|
HDMI ports quantity |
2 |
|
Composite video in |
0 |
|
Component video (YPbPr/YCbCr) in |
0 |
|
DVI port |
No |
|
USB 2.0 ports quantity |
1 |
|
Audio (L/R) in |
1 |
|
S-Video inputs quantity |
0 |
|
Audio (L/R) out |
1 |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Features |
|
Noise level |
29 dB |
|
Noise level (economic mode) |
27 dB |
|
Projection modes |
Ceiling, Front, Rear |
|
Multimedia |
|
Built-in speaker(s) |
Yes |
|
RMS rated power |
5 W |
|
Number of built-in speakers |
2 |
|
Design |
|
Product type |
Ceiling-mounted projector |
|
Market positioning |
Home cinema |
|
Product colour |
White |
|
Placement |
Ceiling |
|
Power |
|
Power source |
AC |
|
Power consumption (typical) |
315 W |
|
Power consumption (economy mode) |
260 W |
|
AC input voltage |
120 - 230 V |
|
Software |
|
Windows operating systems supported |
Yes |
|
Mac compatibility |
Yes |
|
Mac operating systems supported |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Operating relative humidity (H-H) |
0 - 80% |
|
Weight & dimensions |
|
Weight |
5.3 kg |
|
Packaging content |
|
Remote control included |
Yes |
|
Cables included |
AC, HDMI |
|
Carrying case |
Yes |
|
Quick start guide |
Yes |
|
Manual |
Yes |
|
Other features |
|
RS-232 ports |
0 |
|
Maximum digital resolution |
3840 x 2160 pixels |
