Aten 4-Port USB DVI/Audio Slim KVM Switch
|
|
Regularly: $227.00
On Sale: $217.92
Sale Ends:
May 4th, 2025
Manufacturer:
Aten
4-Port USB DVI/Audio Slim KVM Switch
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
38960915
|
CS74D
|
672792004605 |
Active
|
Details
|
General Information |
|
Summary |
The CS74D 4-Port USB DVI KVM Switch allows you to control four computers using one USB mouse, USB keyboard and Digital Visual Interface (DVI) monitor console. It supports digital video devices, such as fl at panel displays, data projectors, plasma displays and digital TVs.
The CS74D comes with ATEN’s Video DynaSync™ technology, which eliminates boot-up display problems and optimizes resolution; it carries several convenient features, such as Power On Detection, 2.1 channel audio capability and USB2.0 peripheral sharing, as well as provides quick and easy methods to access computers. |
|
Ports & interfaces |
|
Number of computers controlled |
4 |
|
Keyboard port type |
USB |
|
Mouse port type |
USB |
|
Video port type |
DVI-D |
|
Console ports |
3.5mm headphone, DVI-D, USB A |
|
Console USB ports quantity |
2 |
|
USB connector type |
USB Type-A |
|
Audio connections |
Yes |
|
Headphone outputs |
1 |
|
DC-in jack |
Yes |
|
Performance |
|
HD type |
WUXGA |
|
Maximum resolution |
1920 x 1200 pixels |
|
Video bandwidth |
60 Hz |
|
Scan interval |
3,5,10,20 s |
|
HDCP |
Yes |
|
Firmware upgradeable |
Yes |
|
Design |
|
Product colour |
Black |
|
Housing material |
Metal |
|
LED indicators |
Yes |
|
Push button |
Yes |
|
Hot keys |
Yes |
|
Display |
|
Built-in display |
No |
|
On Screen Display (OSD) |
No |
|
Power |
|
Power source |
DC |
|
Input voltage |
5.3 V |
|
Power consumption (typical) |
5.3 W |
|
System requirements |
|
Windows operating systems supported |
Yes |
|
Linux operating systems supported |
Yes |
|
Mac operating systems supported |
Yes |
|
Other operating systems supported |
Yes |
|
Sustainability |
|
Compliance certificates |
RoHS |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 80% |
|
Weight & dimensions |
|
Width |
200 mm |
|
Depth |
82 mm |
|
Height |
25 mm |
|
Weight |
510 g |
|
Packaging content |
|
Cables included |
DC, KVM |
|
Manual |
Yes |
|
