Aten 8 x 9 4K HDMI Matrix Switch with Scaler
|
|
Price: $7272.00
Manufacturer:
Aten
8 x 9 4K HDMI Matrix Switch with Scaler
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
38961698
|
VM6809H
|
672792008283 |
Active
|
Details
|
General Information |
|
Summary |
4K is the next generation of image quality for high definition video, which delivers eight million pixels that is four times as much detail as 1080p Full HD resolutions. ATEN’s VM6809H 4K HDMI Matrix Switch with Scaler is compatible with the two latest 4K video resolution standards: 3840 x 2160 and 4096 x 2160. The VM6809H offers powerful HD processing to produce 4K resolutions across nine displays with crystal-clear images.
The VM6809H supports 4K @ 60 Hz, HDMI 2.0* and HDCP 2.2 and features seamless switching that employs an FPGA matrix architecture that ensures continuous video streams, real-time control, and stable signal transmissions. With a built-in high-performance scaler, the VM6809H easily converts various input resolutions into various output display resolutions, giving viewers the best video and picture quality across all displays. The switch integrates video wall functionality with an easy-to-use web GUI that lets you create 17 connection profiles that can be customized into different video wall layouts.
The VM6809H is an ideal solution for applications that require multiple HDMI displays with multiple HDMI sources to be conveniently setup – such as for stage presentations, digital classroom, video conference rooms and any installation that requires real-time synchronization.
*Note: HDMI 2.0 supports 3840 x 2160 @ 30 Hz (4:4:4), 3840 x 2160 @ 60 Hz (4:2:0), 4096 x 2160 @ 30 Hz (4:4:4), 4096 x 2160 @ 60 Hz (4:2:0) resolutions. |
|
Ports & interfaces |
|
Video port type |
HDMI |
|
HDMI ports quantity |
17 |
|
HDMI version |
2.0 |
|
HDMI in |
8 |
|
Number of HDMI outputs |
9 |
|
RJ-45 input ports |
1 |
|
3.5 mm (1/8-inch) out |
Yes |
|
RS-232 ports |
1 |
|
Features |
|
Material |
Metal |
|
Product colour |
Black |
|
HDCP |
Yes |
|
Maximum operating distance |
15 m |
|
Supported graphics resolutions |
3840 x 2160, 4096 x 2160 |
|
Supported video modes |
480p, 720p, 1080p |
|
Bandwidth |
340 MHz |
|
LED indicators |
Yes |
|
Maximum resolution |
4096 x 2160 pixels |
|
Built-in speaker(s) |
No |
|
3D |
Yes |
|
HD type |
4K Ultra HD |
|
Rack capacity |
1U |
|
Input impedance |
100 Ω |
|
Output impedance |
100 Ω |
|
HDCP version |
2.2 |
|
Power |
|
AC adapter input voltage |
100 - 240 V |
|
AC adapter frequency |
50/60 Hz |
|
AC adapter input current |
1 A |
|
Weight & dimensions |
|
Width |
450.3 mm |
|
Depth |
432.4 mm |
|
Height |
44 mm |
|
Weight |
7.05 kg |
|
Packaging content |
|
Quantity per pack |
1 pc(s) |
|
Mounting kit |
Yes |
|
Manual |
Yes |
|
Cables included |
AC |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 80% |
|
Technical details |
|
Compliance certificates |
RoHS |
|
