General Information |
|
Summary |
NETGEAR ® Smart Managed Plus Switches meet this growing need by providing fundamental network features such as VLANs, QoS, and IGMP Snooping that will help optimize the performance of business networks. Smart Managed Plus Switches are the perfect upgrade from the plug-and-play unmanaged switch, delivering essential networking features at a very affordable price. |
|
Management features |
|
Switch type |
Managed |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
5 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
Network |
|
Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
|
Port mirroring |
Yes |
|
Flow control support |
Yes |
|
Link aggregation |
No |
|
Rate limiting |
Yes |
|
VLAN support |
Yes |
|
Virtual LAN features |
Port-based VLAN, Tagged VLAN |
|
Number of VLANs |
64 |
|
Data transmission |
|
MAC address table |
8000 entries |
|
Switching capacity |
10 Gbit/s |
|
Store-and-forward |
Yes |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9000 |
|
Security |
|
DHCP features |
DHCP client |
|
IGMP snooping |
Yes |
|
Loop protection |
Yes |
|
Password protection |
Yes |
|
Design |
|
Rack mounting |
No |
|
Product colour |
Black |
|
LED indicators |
Activity, Link, Power, Speed, System |
|
Performance |
|
Mean time between failures (MTBF) |
2531294 h |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
No |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 3000 m |
|
Weight & dimensions |
|
Width |
94 mm |
|
Depth |
100 mm |
|
Height |
27 mm |
|
Weight |
250 g |
