General Information |
|
Summary |
Fast Wireless Speed with 802.11ac
TP-LINK’s Archer C50 comes with the next generation Wi-Fi standard – 802.11ac, 3 times faster than wireless N speeds and delivering a combined wireless data transfer rate of up to 1.2Gbps. With 300Mbps over the 2.4GHz band and 867Mbps wireless speeds over the crystal clear 5GHz band, the Archer C50 is the superior choice for seamless HD streaming, online gaming and other bandwidth-intensive tasks.
1.2Gbps Dual Band Connections for Lag-Free Work and Entertainment
The Archer C50 operates over both the 2.4GHz and 5GHz bands, ensuring amazing wireless performance. Simultaneous Dual Band offers you the flexibility of two dedicated networks – with multiple times the bandwidth for your needs. Simple tasks like sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video streaming can be processed by the 5GHz band – all at the same time.
2 External Antennas for Optimal Coverage
With 2 external antennas combined with high quality antenna technology, you can maintain high speeds across greater distances. This provides you with optimal wireless coverage and reliability from anywhere in your large home or office.
USB Port for Storage and Sharing
With USB 2.0 port, you can share a printer locally and files & media with networked devices or remotely via FTP server. |
|
WAN connection |
|
Ethernet WAN |
Yes |
|
DSL WAN |
No |
|
SIM card slot |
No |
|
3G/4G USB modem compatibility |
No |
|
WAN connection type |
RJ-45 |
|
Wireless LAN features |
|
Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
|
Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
|
WLAN data transfer rate (max) |
867 Mbit/s |
|
Wi-Fi standards |
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
|
WLAN data transfer rate (first band) |
300 Mbit/s |
|
WLAN data transfer rate (second band) |
867 Mbit/s |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN interface type |
Fast Ethernet |
|
Ethernet LAN data rates |
10,100 Mbit/s |
|
Port forwarding |
Yes |
|
VPN support |
PPTP, L2TP, IPSec |
|
Receiver sensitivity |
5GHz:
11a 54M: -77dBm
11ac VHT20 MCS8: -70dBm
11ac VHT40 MCS9: -66dBm
11ac VHT80 MCS9: -62dBm
2.4GHz:
11g 5.5M: -94dBm
11g 54M: -78dBm
11n HT20 MCS7: -75dBm
11n HT40 MCS7: -72dBm |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
4 |
|
USB port |
Yes |
|
USB 2.0 ports quantity |
1 |
|
Management features |
|
Quality of Service (QoS) support |
Yes |
|
Reset button |
Yes |
|
WPS push button |
Yes |
|
Security |
|
Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
|
Firewall |
Yes |
|
Stateful Packet Inspection (SPI) |
Yes |
|
DoS attack prevention |
Yes |
|
Filtering |
Yes |
|
MAC address filtering |
Yes |
|
IP address filtering |
Yes |
|
DMZ support |
Yes |
|
Protocols |
|
DHCP client |
Yes |
|
DHCP server |
Yes |
|
Universal Plug and Play (UPnP) |
Yes |
|
Design |
|
Product type |
Tabletop router |
|
Product colour |
Black |
|
On/off switch |
Yes |
|
Packaging content |
|
Cables included |
LAN (RJ-45) |
|
AC adapter included |
Yes |
|
Quick start guide |
Yes |
|
Antenna |
|
Antenna design |
External |
|
Antennas quantity |
2 |
|
Features |
|
Built-in processor |
Yes |
|
Processor cores |
1 |
|
Power |
|
Power source type |
AC |
|
Output voltage |
9 V |
|
Output current |
0.85 A |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
10 - 90% |
|
Storage relative humidity (H-H) |
5 - 90% |
|
Weight & dimensions |
|
Width |
182.9 mm |
|
Depth |
123.5 mm |
|
Height |
32.1 mm |
|
Packaging data |
|
Package width |
290 mm |
|
Package depth |
240 mm |
|
Package height |
76 mm |
|
Package weight |
670 g |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
