Scanning |
|
Maximum scan size |
108 x 245 mm |
|
Optical scanning resolution |
600 x 600 DPI |
|
Duplex scanning |
Yes |
|
Colour scanning |
Yes |
|
Input colour depth |
24 bit |
|
ADF scan speed (b/w, A4) |
120 ppm |
|
Design |
|
Built-in display |
No |
|
Performance |
|
Sensor type |
CMOS |
|
Light source |
RGB LED |
|
Input capacity |
|
Auto document feeder (ADF) input capacity |
150 sheets |
|
Paper handling |
|
Card thickness (max) |
0.2 mm |
|
Auto Document Feeder (ADF) media weight |
64 - 157 g/m² |
|
Ports & interfaces |
|
USB port |
Yes |
|
USB version |
2.0 |
|
Standard interfaces |
USB 2.0 |
|
Power |
|
Power consumption (typical) |
25 W |
|
Sleep mode |
Yes |
|
Power consumption (sleep) |
2.7 W |
|
Weight & dimensions |
|
Width |
170 mm |
|
Depth |
238.2 mm |
|
Height |
203.6 mm |
|
Weight |
3.2 kg |
|
Packaging content |
|
Cables included |
AC, USB |
|
Bundled software |
Ranger Transport API, Canon Scanning Utility |
|
System requirements |
|
Windows operating systems supported |
Windows 10, Windows 7, Windows 8.1, Windows Vista |
|
Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012 R2 |
