Aten 4K HDMI/DVI to HDMI Converter with Audio De-embedder
|
|
Regularly: $169.00
On Sale: $162.24
Sale Ends:
April 26th, 2024
Manufacturer:
Aten
4K HDMI/DVI to HDMI Converter with Audio De-embedder
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
52365372
|
VC881
|
- |
Active
|
Details
|
General Information |
|
Summary |
ATEN VC881 is a high-quality HDMI/DVI to HDMI converter with audio de-embedding function. Input a DVI signal and it converts the signal to HDMI signal or input an HDMI signal and it extracts the HDMI audio signal. Advanced video support provides a better-defined connection with video resolutions up to 4K and complies with HDCP 1.4.
The VC881 offers the fl exibility to support signal interface conversion (DVI to HDMI) and HDMI audio de-embedding. For HDMI audio de-embedding function, the VC881 splits the audio from HDMI video and converts it to S/PDIF, Coaxial, or a RCA Stereo Audio signal to support an audio system that is separate from the display. This allows HDMI video to continue to the display while supplying audio to an audio system near the HDMI source. In addition, the VC881 supports ARC to simplify the setting by eliminating the need for any separate S/PDIF audio connection.
The compact enclosure design and audio de-embedding capability make the VC881 ideal for bars, public transportation stations, and home theater settings. |
|
Features |
|
Product colour |
Black |
|
Housing material |
Metal |
|
Video |
|
Maximum video resolution |
3840 x 2160 pixels |
|
Bandwidth |
340 MHz |
|
HDCP |
Yes |
|
Ports & interfaces |
|
Host interface |
HDMI + DVI |
|
Output interface |
HDMI |
|
Video in |
2 |
|
Video out |
1 |
|
Audio output |
Audio (L, R), Coax, S/PDIF Optical |
|
Power |
|
External power adapter |
Yes |
|
Power consumption (typical) |
1.767 W |
|
Technical details |
|
Sustainability certificates |
RoHS |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 80% |
|
Weight & dimensions |
|
Width |
202 mm |
|
Depth |
84.9 mm |
|
Height |
25 mm |
|
Weight |
470 g |
|
Packaging data |
|
AC adapter included |
Yes |
|
Quick installation guide |
Yes |
|
Quantity |
1 |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
|
