SeaSonic S12III SSR-500GB3 500 Watt 80+ Bronze ATX Power Supply
|
|
Price: $88.00
Manufacturer:
SeaSonic
Intel ATX, 500W, 12 V, 30000 h, 110 V - 240 V, 10 A - 5 A, 50 Hz - 60 Hz, PCI-E, SATA, FDD, Peripheral, 140 x 150 x 86 mm
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
53514885
|
SSR-500GB3
|
4711173875215 |
Active
|
Details
|
General Information |
|
Summary |
S12III SERIES
The S12III Bronze Series is available in the standard ATX Form Factor and in wattages that are most common for a PC system. The Seasonic S12III-Series achieves 80 PLUS® Bronze standard of providing at least 82 %, 85 % and 82 % power usage efficiency at 20 %, 50 % and 100 % operating loads, respectively. This efficiency, combined with Active Power Factor Correction, enables the S12III Bronze series power supplies to lessen energy waste, which translates into savings on the costs of energy costs for its users. In addition to being greatly efficient, the S12III units utilize the LLC resonant converter design, and the industry’s leading Smart and Silent Fan Control (S2FC).
80 PLUS®BRONZE
The 80 PLUS® Bronze certification indicates that a high percentage of the electricity is converted into useful power, therefore there is less heat lost and more money saved on the electricity bill.
The 80 PLUS® Bronze certification guarantees greater than 82 %, 85 % and 82 % efficiency at 20 %, 50 % and 100 % operating loads, respectively. Sea Sonic’s Bronze Series is an economical choice with great performance and high built-in value.
S2FC - SMART AND SILENT FAN CONTROL
The intelligent thermal circuit feature is designed to find the optimal balance between the necessity to cool the components and the need to run the power supply in the most silent manner possible. |
|
Power |
|
Total power |
500 W |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50 - 60 Hz |
|
Input current |
8 - 4 A |
|
Combined power (+3.3V) |
100 W |
|
Combined power (+12V) |
480 W |
|
Combined power (+5V) |
100 W |
|
Combined power (-12V) |
3.6 W |
|
Combined power (+5Vsb) |
12.5 W |
|
Max output current (+3.3V) |
20 A |
|
Max output current (+12V) |
40 A |
|
Max output current (+5V) |
20 A |
|
Max output current (-12V) |
0.3 A |
|
Max output current (+5Vsb) |
2.5 A |
|
Power protection features |
Over power, Over voltage, Short circuit, Under voltage |
|
Ports & interfaces |
|
Motherboard power connector |
20+4 pin ATX |
|
Peripheral (Molex) power connectors (4-pin) |
3 |
|
Motherboard power cable length |
55 cm |
|
Number of SATA power connectors |
4 |
|
SATA power cable length |
400 mm |
|
Peripheral (Molex) power cable length |
450 mm |
|
PCI Express power connectors (8-pin) |
2 |
|
PCI Express power cable length |
55 cm |
|
CPU P4 connector (4-pin) |
1 |
|
CPU power cable length |
60 cm |
|
Floppy drive power connector |
1 |
|
Floppy disk drive connector |
Yes |
|
Floppy disk drive cable length |
12 cm |
|
Cabling type |
Non-Modular |
|
Performance |
|
Purpose |
PC |
|
Power supply unit (PSU) form factor |
ATX |
|
80 PLUS certification |
80 PLUS Bronze |
|
Bearing technology |
Sleeve |
|
Mean time between failures (MTBF) |
100000 h |
|
Design |
|
Product colour |
Black |
|
Cooling type |
Active |
|
Fan diameter |
12 cm |
|
On/off switch |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Packaging content |
|
Cables included |
AC |
|
Certificates |
|
Compliance certificates |
RoHS |
|
Certification |
WEEE, REACH |
|
Safety regulation & standards |
|
Safety |
cTUVus, TUV, Gost-R, CB , BSMI, CCC, CE, FCC, C-tick |
|
Weight & dimensions |
|
Width |
150 mm |
|
Depth |
140 mm |
|
Height |
86 mm |
|
Packaging data |
|
Manual |
Yes |
|
Package type |
Box |
|
Technical details |
|
Sustainability certificates |
ENERGY STAR |
|
Logistics data |
|
Harmonized System (HS) code |
84733020 |
|
