HPE Aruba 2930F 12G PoE+ 2G/2SFP+ Switch

Home :: Networking :: Wired Networking :: Network Switches ::


Regularly: $2575.00
On Sale: $2472.00    Sale Ends: April 12th, 2024

Manufacturer: HPE

Aruba 2930F 12G PoE+ 2G/2SFP+ Switch

Availability
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
Product # Manufacturer # UPC # Status
54082143 JL693A#ABA 190017368207 Active

Details

General Information
Summary The Aruba 2930F Switch Series is designed for customer creating digital workplaces optimized for mobile users. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Virtual Switching Framework (VSF) provides stacking scale and simplicity for enterprise edge, SMB and branch offices. The 2930F delivers performance and value with support for RIP routing, Access OSPF, 10GbE uplinks, up to 740W PoE+, robust QoS, and requires no software licensing.

What's new
- Aruba Layer 3 switch series that is easy to deploy and manage with Aruba ClearPass Policy Manager and Aruba AirWave.
- Simplify with zero touch provisioning (ZTP) and cloud-based Aruba Central support.
- Scale with 8 chassis VSF stacking.
- Convenient built-in 1GbE or 10GbE uplinks and up to 740W PoE+.

Features

High-Performance Access Layer Switches
- The Aruba 2930F Switch Series provides performance, security, and ease of use for enterprise edge, SMB, and branch office networks.
- Optimized for the digital workplace with unified management tools such as Aruba ClearPass Policy Manager, Aruba Airwave and Aruba Central. Provides optimal configuration automatically when connected to Aruba access points for PoE priority, VLAN configuration, and rogue AP containment.
- Stacking with Virtual Switching Framework (VSF) and convenient built-in 1GbE or 10GbE uplinks and PoE+ models deliver right-size network access performance.
- Robust Layer 3 feature set includes Access OSPF, static and RIP routing, ACLs, sFlow, IPv6 with no software licensing required.

Performance and Power at the Edge
- The Aruba 2930F Switch Series is designed with a powerful Aruba ProVision ASIC, to enable the mobile campus with SDN optimizations, low latency, increased packet buffering, and adaptive power consumption.
- Increase performance with selectable queue configurations and associated memory buffering that meets your specific network application requirements.
- Virtual Switching Framework (VSF) virtualizes up to eight physical switches into one logical device for simpler, flatter, more agile networks.
- Supports up to 740W of internal PoE+ power for wireless access points, cameras and phones.

Security and Quality of Service You Can Rely on
- The Aruba 2930F Switch Series includes security and quality of services features to build a network that meets ever-changing corporate policies and compliances while protecting your data from both inside and outside attacks.
- Flexible authentication options include standards based security protocols such as 802.1X, MAC and Web Authentication, to enhance security and policy-driven application authentication.
- Powerful, multilevel-access security controls include source-port filtering, RADIUS/TACACS+, SSL, Port Security, and MAC address lockout.

Simplify with Integrated Wired/Wireless Management
- The Aruba 2930F Switch Series supports Aruba ClearPass Policy Manager for unified and consistent policy between wired and wireless users and simplifies implementation and management of guest login, user onboarding, network access, security, QoS, and other network policies.
- Supports Aruba Airwave Network Management software to provide common platform for Zero Touch Provisioning management, and monitoring for wired and wireless network devices.
- Cloud-based management supported by Aruba Central.
- RMON and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms and events.
- Out-of-band Ethernet management port keeps management traffic segmented from your network data traffic.
Management features
Switch type Managed
Switch layer L3
Quality of Service (QoS) support Yes
Web-based management Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 12
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity 2
Network
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
10G support Yes
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex Yes
IP routing Yes
Routing entries 10000
Flow control support Yes
Link aggregation Yes
Rate limiting Yes
Auto MDI/MDI-X Yes
Spanning tree protocol Yes
Auto-sensing Yes
VLAN support Yes
Data transmission
MAC address table 32768 entries
Switching capacity 68 Gbit/s
Throughput 41.7 Mpps
Latency (1 Gbps) 3.8 µs
Latency (10 Gbps) 2.9 µs
Packet buffer memory 12.38 MB
Security
DHCP features DHCP server
Access Control List (ACL) Yes
IGMP snooping Yes
SSH/SSL support Yes
Multicast features
Multicast support Yes
Protocols
Routing protocols IP
IPv4 FIB entries 10000
IPv6 FIB entries 5000
Design
Rack mounting Yes
Stackable Yes
Form factor 1U
Product colour Black
Performance
Built-in processor Yes
Processor model ARM Cortex-A9
Processor frequency 1016 MHz
Memory type DDR3-SDRAM
Internal memory 1024 MB
Power
Power source AC
Power supply included Yes
AC input voltage 90 - 264 V
AC input frequency 50 - 60 Hz
Power consumption (max) 170 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Total Power over Ethernet (PoE) budget 139 W
Operational conditions
Operating temperature (T-T) 0 - 45 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 15 - 95%
Storage relative humidity (H-H) 15 - 95%
Heat dissipation 68.2 BTU/h
Weight & dimensions
Width 254 mm
Depth 254 mm
Height 43.9 mm
Weight 2.2 kg
