Features |
|
2.4 GHz |
Yes |
|
5 GHz |
Yes |
|
Maximum data transfer rate |
1000 Mbit/s |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
|
MIMO |
Yes |
|
MIMO type |
Multi User MIMO |
|
Modulation |
16-QAM, 64-QAM, 256-QAM, BPSK, CCK, QPSK |
|
Fit AP mode features |
Wireless distribution system (WDS) |
|
Wi-Fi roaming |
Yes |
|
Fast roaming |
Yes |
|
VLAN support |
Yes |
|
Virtual LAN features |
Tagged VLAN, SSID-based VLAN assignment |
|
Number of VLAN IDs |
16 |
|
Band steering |
Yes |
|
Configuring Location Settings (CLI) |
Yes |
|
Quality of Service (QoS) support |
Yes |
|
Security |
|
Security algorithms |
SNMP, SNMPv3 |
|
MAC address filtering |
Yes |
|
Service Set Identifier (SSID) features |
SSID broadcast on/off |
|
Number of SSID supported |
64 |
|
Auto Wireless Distribution System (WDS) |
Yes |
|
Remote Authentication Dial-In User Service (RADIUS) |
Yes |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
1 |
|
USB 2.0 ports quantity |
0 |
|
WAN connection |
Ethernet (RJ-45) |
|
DC-in jack |
Yes |
|
Power |
|
Power over Ethernet (PoE) |
Yes |
|
Power consumption (max) |
12.6 W |
|
Design |
|
Placement |
Wall |
|
Product colour |
White |
|
International Protection (IP) code |
IP67 |
|
Reset button |
Yes |
|
Internal |
No |
|
Antenna |
|
Antennas quantity |
4 |
|
Antenna gain level (max) |
5 dBi |
|
Antenna connector type |
SMA |
|
Certificates |
|
Certification |
FCC, CE |
|
Weight & dimensions |
|
Width |
111.2 mm |
|
Depth |
173.6 mm |
|
Height |
30.3 mm |
|
Weight |
295 g |
|
Packaging data |
|
Package width |
152 mm |
|
Package depth |
248 mm |
|
Package height |
117 mm |
|
Package weight |
876.5 g |
|
Packaging content |
|
AC adapter included |
Yes |
|
Cables included |
AC |
|
Quick start guide |
Yes |
|
Operational conditions |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Operating temperature (T-T) |
-20 - 60 °C |
|
Storage temperature (T-T) |
-40 - 80 °C |
|
Storage relative humidity (H-H) |
0 - 90% |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
|
Master (outer) case width |
328 mm |
|
Master (outer) case length |
493 mm |
|
Master (outer) case height |
291 mm |
|
Master (outer) case gross weight |
7.8 kg |
|
Products per master (outer) case |
8 pc(s) |
