General Information |
|
Summary |
Wi-Fi 6 delivers a huge boost in speed and total capacity. Get on the latest Wi-Fi technology to wipe out all the annoying jittering and slow down and enjoy the future network that loads faster and connects more. The latest 1024-QAM and higher symbol rate combine to boost speeds for newer devices to the Gigabit level. Connect to a 1 Gbps Wi-Fi network with your phone or laptop and enjoy speeds comparable to plugging in an Ethernet cable. Wi-Fi 6 efficiently transmits data, enabling data packets for different applications to share one broadcast and cut the latency. Enjoy flawless video and audio chats, better gaming speeds and instantaneous video loading on different devices—all at the same time. A 1.5 GHz triple-core CPU provides overwhelming power to tackle huge amounts of data transferring, minimizing the latency within your network. Enjoy instant response when you click the play button for online playback and get better quality for the online video chatting. Get Next-Gen Wi-Fi speeds up to 1.5 Gbps. Instant response to all your network activity with a 1.5 GHz triple-core CPU. Broader Coverage 4 antennas and beamforming technology focus signal towards individual clients for broader coverage. Connect Dozens of devices more simultaneous connections and higher average throughput with ofdma. Full gigabit ports take full advantages of broadband speeds up to 1 gbps. Easy setup finish your network upgrade in minutes with tether app. Easy and Smart Connect a new device to your Wi-Fi without using the password, but your voice. EasyMesh-Compatible Flexibly creates a mesh network by connecting to an easymesh-compatible router for seamless whole-home coverage. |
|
WAN connection |
|
Ethernet WAN |
Yes |
|
DSL WAN |
No |
|
SIM card slot |
No |
|
3G/4G USB modem compatibility |
No |
|
WAN connection type |
RJ-45 |
|
Wireless LAN features |
|
Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
|
Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
|
WLAN data transfer rate (max) |
1500 Mbit/s |
|
Wi-Fi standards |
Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax) |
|
WLAN data transfer rate (first band) |
300 Mbit/s |
|
WLAN data transfer rate (second band) |
1201 Mbit/s |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN interface type |
Gigabit Ethernet |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
|
Port forwarding |
Yes |
|
Dynamic DNS (DDNS) |
Yes |
|
Receiver sensitivity |
5 GHz:
11a 6Mbps:-97dBm, 11a 54Mbps:-79dBm
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-66dBm
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-63dBm
11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS11:-60dBm
11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-63dBm
11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-60dBm
11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-58dBm
2.4 GHz:
11g 6Mbps:-91dBm, 11a 54Mbps:-74dBm
11n HT20_MCS0:-90dBm, 11n HT20_MCS7:-73dBm
11n HT40_MCS0:-88dBm, 11n HT40_MCS7:-70dBm |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
4 |
|
USB port |
No |
|
Memory card slot(s) |
No |
|
DC-in jack |
Yes |
|
Management features |
|
Reset button |
Yes |
|
WPS push button |
Yes |
|
Security |
|
Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
|
Firewall |
Yes |
|
Firewall security |
SPI |
|
Guest access |
Yes |
|
DMZ support |
Yes |
|
Protocols |
|
DHCP client |
Yes |
|
DHCP server |
Yes |
|
Universal Plug and Play (UPnP) |
Yes |
|
Supported network protocols |
IPv4, IPv6 |
|
Design |
|
Product type |
Tabletop router |
|
Product colour |
Black |
|
On/off switch |
Yes |
|
Certificates |
|
Certification |
FCC, CE, RoHS |
|
Packaging content |
|
Cables included |
LAN (RJ-45) |
|
AC adapter included |
Yes |
|
Quick installation guide |
Yes |
|
Packaging content |
1 x TP-Link Archer AX1500 Wi-Fi 6 Router, Black |
|
Antenna |
|
Antenna design |
External |
|
Antennas quantity |
4 |
|
Transmit power |
CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.25 GHz); FCC:<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) |
|
Features |
|
Built-in processor |
Yes |
|
Processor frequency |
1500 MHz |
|
Processor cores |
3 |
|
Internal memory |
256 MB |
|
Flash memory |
16 MB |
|
Power |
|
Power source type |
AC |
|
Output voltage |
12 V |
|
Output current |
1 A |
|
System requirements |
|
Browser supported |
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
|
Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows XP |
|
Linux operating systems supported |
Yes |
|
Mac operating systems supported |
Yes |
|
Mac compatibility |
Yes |
|
Weight & dimensions |
|
Width |
260 mm |
|
Depth |
126 mm |
|
Height |
33 mm |
|
Weight |
370 g |
|
Packaging data |
|
Package width |
124 mm |
|
Package depth |
300 mm |
|
Package height |
38 mm |
|
Package weight |
780 g |
|
Number of products included |
1 pc(s) |
|
Logistics data |
|
Quantity per pack |
1 pc(s) |
|
Harmonized System (HS) code |
85176990 |
|
Country of origin |
Malaysia |
