General Information |
|
Summary |
This USB-C to HDMI Adapter Converter is an easy and convenient solution for connecting an HDMI monitor to a USB-C computer in your home or your office. This adapter converter carries a digital video signal, supports up to a 4K resolution and meets the requirements of high performance applications.
Avoid frustration by simply plugging the adapter into your computer, then attach to the existing HDMI cable from your monitor or projector. The portable, compact design also makes it easy to carry in a laptop bag when traveling or on the go.
This adapter converter automatically converts the digital USB-C signal to HDMI, supporting full HD up to a 4K resolution at 60Hz |
|
Performance |
|
DVI output |
No |
|
HDMI output |
Yes |
|
DisplayPort output |
No |
|
Number of displays supported |
1 |
|
USB connector type |
USB Type-C |
|
USB connector gender |
Male |
|
Maximum resolution |
3840 x 2160 pixels |
|
Refresh rate at maximum resolution |
60 Hz |
|
Maximum resolution (HDMI) |
3840 x 2160 pixels |
|
Supported graphics resolutions |
3840 x 2160 |
|
Supported video modes |
2160p |
|
Certification |
CE, 2011/65/EU ROHS 2 |
|
Design |
|
Product colour |
Black |
|
Housing material |
Polyvinyl chloride (PVC) |
|
Power |
|
Power consumption (max) |
0.396 W |
|
Input voltage |
3.3 V |
|
Weight & dimensions |
|
Width |
23 mm |
|
Depth |
43 mm |
|
Height |
12 mm |
|
Weight |
4.5 g |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-10 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 90% |
|
Logistics data |
|
Harmonized System (HS) code |
84733020 |
