General Information |
|
Summary |
The ALOGIC USB-C Dock PLUS is the next generation USB-C peripheral designed to work with the latest USB-C and Thunderbolt 3 enabled computers. Featuring ALOGIC latest advancement in the R&D of USB-C technology this next generation dock PLUS is one of the most advanced products in its class across the industry. Truly Universal: Connect all you want The dock PLUS features a full array of ports ranging from 1 x HDMI with support for 4K@30Hz 1 x Mini DisplayPort with support for 4k@30Hz 1 x Gigabit Ethernet for wired ethernet 2 x USB 3.0 (USB-A) ports for your standard USB accessories 1 x Micro SD and SD Card Readers and 1 x USB-C port with support for up to 100W of Power Delivery for charging you laptop when connected to a suitable USB-C Charger. The USB-C port and Data transmission from the same port. The USB-C port also supports Data transmission from the same port along with power. Single 4K or Dual 1080p Monitors:The Dock PLUS supports either a single monitor with up to 4K resolution when one of the HDMI or It can also support two monitors with up to 1080p FULL HD resolution simultaneously when the HDMI and Mini DisplayPort outputs are used together.An active Mini DisplayPort cable/adapter must be used when the connection from the Mini DisplayPort output on the dock is being converted to a HDMI/DVI/VGA connection.The Dual monitor support is only compatible with Windows 10 and above computers. Only single monitor is supported on Mac computers. Eliminate Magnetic Interference:The dock features comprehensive shielding to eliminate all magnetic interference caused by Bluetooth Wi-fi or any other frequencies. This help improves the performance of your laptop and tablet across different locations and environments. Power Delivery 3.0 Technology: Data + Power The Docking station uses the latest Power Delivery (PD 3.0) specification that lets you charge your MacBook or other USB-C enabled laptop with up to 100W of power. The USB-C port in this next generation dock also supports data transmission for connecting a USB-C storage device peripheral smart phone etc for transferring data. |
|
Ports & interfaces |
|
Connectivity technology |
Wired |
|
Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
|
HDMI ports quantity |
1 |
|
Microphone in |
No |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
|
Mini DisplayPorts quantity |
1 |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Copper ethernet cabling technology |
10BASE-T, 100BASE-T, 1000BASE-T |
|
Performance |
|
Product colour |
Grey |
|
Card reader integrated |
Yes |
|
Compatible memory cards |
MicroSD (TransFlash), SD |
|
Maximum digital resolution |
3840 x 2160 pixels |
|
Housing material |
Aluminium |
|
Power |
|
Power supply |
100 W |
|
Software |
|
Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64 |
|
Mac operating systems supported |
Yes |
|
Weight & dimensions |
|
Width |
52 mm |
|
Depth |
136.1 mm |
|
Height |
15 mm |
|
Packaging data |
|
Quantity per pack |
1 pc(s) |
|
Packaging content |
|
Manual |
Yes |
|
Logistics data |
|
Harmonized System (HS) code |
84733020 |
