General Information |
|
Summary |
10th Gen Intel Core i3-10105 desktop processor optimized for everyday computing. Thermal solution included in the box. Compatible with 500 series & select 400 series chipset based motherboards. Refer to motherboard vendor for compatiblity details. 65W. |
|
Processor |
|
Processor family |
Intel® Core™ i3 |
|
Processor cores |
4 |
|
Processor socket |
LGA 1200 (Socket H5) |
|
Processor lithography |
14 nm |
|
Package type |
Box |
|
Cooler included |
Yes |
|
Processor manufacturer |
Intel |
|
Processor model |
i3-10105 |
|
Processor base frequency |
3.7 GHz |
|
Processor operating modes |
64-bit |
|
Processor generation |
10th gen Intel® Core™ i3 |
|
Component for |
PC |
|
Processor threads |
8 |
|
System bus rate |
8 GT/s |
|
Processor boost frequency |
4.4 GHz |
|
Processor cache |
6 MB |
|
Processor cache type |
Smart Cache |
|
Thermal Design Power (TDP) |
65 W |
|
Memory bandwidth supported by processor (max) |
41.6 GB/s |
|
Processor codename |
Comet Lake |
|
Processor ARK ID |
201894 |
|
Memory |
|
Memory channels |
Dual-channel |
|
Maximum internal memory supported by processor |
128 GB |
|
Memory types supported by processor |
DDR4-SDRAM |
|
Memory clock speeds supported by processor |
2666 MHz |
|
ECC |
No |
|
Memory bandwidth (max) |
41.6 GB/s |
|
Graphics |
|
On-board graphics card |
Yes |
|
Discrete graphics card |
No |
|
On-board graphics card model |
Intel® UHD Graphics 630 |
|
Discrete graphics card model |
Not available |
|
Maximum on-board graphics card memory |
64 GB |
|
On-board graphics card base frequency |
350 MHz |
|
On-board graphics card dynamic frequency (max) |
1.1 MHz |
|
Number of displays supported (on-board graphics) |
3 |
|
On-board graphics card 4K support |
Yes |
|
On-board graphics card DirectX version |
12.0 |
|
On-board graphics card OpenGL version |
4.5 |
|
On-board graphics card maximum resolution (DisplayPort) |
4096 x 2304 pixels |
|
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) |
4096 x 2304 pixels |
|
On-board graphics card maximum resolution (HDMI) |
4096 x 2160 pixels |
|
On-board graphics card refresh rate at maximum resolution (DisplayPort) |
60 Hz |
|
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) |
60 Hz |
|
On-board graphics card refresh rate at maximum resolution (HDMI) |
30 Hz |
|
On-board graphics card ID |
0x9BC8 |
|
Features |
|
Execute Disable Bit |
Yes |
|
Idle States |
Yes |
|
Thermal Monitoring Technologies |
Yes |
|
Market segment |
Desktop |
|
Use conditions |
PC/Client/Tablet |
|
Maximum number of PCI Express lanes |
16 |
|
PCI Express slots version |
3.0 |
|
PCI Express configurations |
1x16, 2x8, 1x8+2x4 |
|
Supported instruction sets |
SSE4.1, SSE4.2, AVX 2.0 |
|
Scalability |
1S |
|
CPU configuration (max) |
1 |
|
Embedded options available |
No |
|
Thermal solution specification |
PCG 2015C |
|
Export Control Classification Number (ECCN) |
5A992.C |
|
Commodity Classification Automated Tracking System (CCATS) |
G077159 |
|
Processor special features |
|
Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
|
Intel® Identity Protection Technology (Intel® IPT) |
Yes |
|
Intel® Turbo Boost Technology |
2.0 |
|
Intel® Quick Sync Video Technology |
Yes |
|
Intel® InTru™ 3D Technology |
Yes |
|
Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
|
Intel® AES New Instructions (Intel® AES-NI) |
Yes |
|
Enhanced Intel SpeedStep Technology |
Yes |
|
Intel Trusted Execution Technology |
No |
|
Intel® Thermal Velocity Boost |
No |
|
Intel® Turbo Boost Technology 2.0 frequency |
4.4 GHz |
|
Intel® Transactional Synchronization Extensions |
No |
|
Intel Enhanced Halt State |
Yes |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel® Secure Key |
Yes |
|
Intel Stable Image Platform Program (SIPP) |
No |
|
Intel® OS Guard |
Yes |
|
Intel Clear Video Technology |
Yes |
|
Intel Software Guard Extensions (Intel SGX) |
Yes |
|
Intel 64 |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
|
Intel Turbo Boost Max Technology 3.0 |
No |
|
Intel® Optane™ Memory Ready |
Yes |
|
Intel® Boot Guard |
Yes |
|
Intel® vPro™ Platform Eligibility |
No |
|
Intel® Stable IT Platform Program (SIPP) |
No |
|
Operational conditions |
|
Tjunction |
100 °C |
|
Technical details |
|
Supported memory types |
DDR4-SDRAM |
|
Launch date |
Q1'21 |
|
OpenGL support |
Yes |
|
Status |
Launched |
|
Bus speed |
8 GT/s |
|
Logistics data |
|
Harmonized System (HS) code |
85423119 |
|
Weight & dimensions |
|
Processor package size |
37.5 x 37.5 mm |
|
Other features |
|
Maximum internal memory |
128 GB |
