General Information |
|
Summary |
330VA UPS Omni Smart Hospital |
|
Features |
|
Output power capacity |
0.33 kVA |
|
Output power |
215 W |
|
Audible alarm(s) |
Yes |
|
Battery |
|
Typical backup time at full load |
18 min |
|
Typical backup time at half load |
46 min |
|
Battery recharge time |
4.5 h |
|
Hot-swap battery |
Yes |
|
Design |
|
Form factor |
Tower |
|
Product colour |
Black |
|
Cable length |
1.8 m |
|
LED indicators |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-15 - 50 °C |
|
Operating relative humidity (H-H) |
0 - 95% |
|
Certificates |
|
Certification |
UL1778, CSA, FCC Part 15 Category B, ROHS |
|
Weight & dimensions |
|
Width |
133.4 mm |
|
Depth |
190.5 mm |
|
Height |
273 mm |
|
Weight |
11.3 kg |
|
Packaging data |
|
Package width |
203.2 mm |
|
Package depth |
256.5 mm |
|
Package height |
355.6 mm |
|
Package weight |
12.6 kg |
|
Logistics data |
|
Master (outer) case width |
203.2 mm |
|
Master (outer) case length |
256.5 mm |
|
Master (outer) case height |
355.6 mm |
|
Master (outer) case gross weight |
12.6 kg |
|
Products per master (outer) case |
1 pc(s) |
|
Country of origin |
China |
|
Other features |
|
Output connections |
4 x 5-15R |
|
Input connection type |
5-15P |
|
Dimensions (WxDxH) |
133 x 184 x 273 mm |
|
Nominal output voltage |
120 V |
|
Nominal input voltage |
120 V |
|
Package dimensions (WxDxH) |
216 x 279 x 356 mm |
