General Information |
Summary |
Intel® Trusted Execution Technology Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Intel® Virtualization Technology for Directed I/O (VT-d) Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® Virtualization Technology (VT-x) Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® 64 Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Intel® Clear Video HD Technology Intel® Clear Video HD Technology, like its predecessor, Intel® Clear Video Technology, is a suite of image decode and processing technologies built into the integrated processor graphics that improve video playback, delivering cleaner, sharper images, more natural, accurate, and vivid colors, and a clear and stable video picture. Intel® Clear Video HD Technology adds video quality enhancements for richer color and more realistic skin tones.
Cache CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.
Intel® AES New Instructions Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel® InTru™ 3D Technology Intel® InTru™ 3D Technology provides stereoscopic 3-D Blu-ray* playback in full 1080p resolution over HDMI* 1.4 and premium audio.
Idle States Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.
Intel® Turbo Boost Technology Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Max Turbo Frequency Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.
Execute Disable Bit Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.
Intel® Hyper-Threading Technology Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Instruction Set An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel’s instruction set this processor is compatible with.
Intel® Quick Sync Video Intel® Quick Sync Video delivers fast conversion of video for portable media players, online sharing, and video editing and authoring.
Intel vPro® Platform Eligibility The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.
Intel® VT-x with Extended Page Tables (EPT) Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.
Enhanced Intel SpeedStep® Technology Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Intel® Clear Video Technology Intel® Clear Video Technology is a suite of image decode and processing technologies built into the integrated processor graphics that improve video playback, delivering cleaner, sharper images, more natural, accurate, and vivid colors, and a clear and stable video picture.
Secure Key Intel® Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms.
Intel® Turbo Boost Technology 2.0 Frequency Intel® Turbo Boost Technology 2.0 Frequency is the maximum single core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.
Intel® Software Guard Extensions (Intel® SGX) Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications’ sensitive routines and data. Intel® SGX provides developers a way to partition their code and data into CPU hardened trusted execution environments (TEE’s).
Instruction Set Extensions Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).
Thermal Monitoring Technologies Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.
Intel® Optane™ Persistent Memory Supported Intel® Optane™ persistent memory is a revolutionary tier of non-volatile memory that sits between memory and storage to provide large, affordable memory capacity that is comparable to DRAM performance. Delivering large system-level memory capacity when combined with traditional DRAM, Intel Optane persistent memory is helping transform critical memory constrained workloads – from cloud, databases, in-memory analytics, virtualization, and content delivery networks.
Intel® Memory Protection Extensions (Intel® MPX) Intel® Memory Protection Extensions (Intel® MPX) provides a set of hardware features that can be used by software in conjunction with compiler changes to check that memory references intended at compile time do not become unsafe at runtime due to buffer overflow or underflow.
Intel® Boot Guard Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.
Intel® Transactional Synchronization Extensions Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software. |
Processor |
Processor family |
Intel Xeon E |
Processor cores |
4 |
Processor socket |
LGA 1200 (Socket H5) |
Processor lithography |
14 nm |
Box |
Yes |
Cooler included |
No |
Processor manufacturer |
Intel |
Processor model |
E-2324G |
Processor base frequency |
3.1 GHz |
Processor operating modes |
64-bit |
Component for |
Server/workstation |
Processor threads |
4 |
System bus rate |
8 GT/s |
Processor boost frequency |
4.6 GHz |
Processor cache |
8 MB |
Processor cache type |
Smart Cache |
Thermal Design Power (TDP) |
65 W |
Processor ARK ID |
212255 |
Memory |
Memory channels |
Dual-channel |
Maximum internal memory supported by processor |
128 GB |
Memory types supported by processor |
DDR4-SDRAM |
ECC |
Yes |
Graphics |
On-board graphics card |
Yes |
Discrete graphics card |
No |
On-board graphics card model |
Intel UHD Graphics P750 |
Discrete graphics card model |
Not available |
Maximum on-board graphics card memory |
64 GB |
On-board graphics card base frequency |
350 MHz |
On-board graphics card dynamic frequency (max) |
1300 MHz |
Number of displays supported (on-board graphics) |
1 |
On-board graphics card 4K support |
Yes |
On-board graphics card DirectX version |
12.1 |
On-board graphics card OpenGL version |
4.5 |
On-board graphics card maximum resolution (DisplayPort) |
5120 x 3200 pixels |
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) |
5120 x 3200 pixels |
On-board graphics card maximum resolution (HDMI) |
4096 x 2160 pixels |
On-board graphics card refresh rate at maximum resolution (DisplayPort) |
60 Hz |
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) |
60 Hz |
On-board graphics card refresh rate at maximum resolution (HDMI) |
60 Hz |
On-board graphics card ID |
0x4C9A |
Number of execution units |
32 |
Features |
Execute Disable Bit |
Yes |
Idle States |
Yes |
Thermal Monitoring Technologies |
Yes |
Market segment |
Server |
Use conditions |
Server/Enterprise |
Maximum number of PCI Express lanes |
20 |
PCI Express slots version |
4.0 |
PCI Express configurations |
1x16+1x4, 2x8+1x4, 1x8+3x4 |
Supported instruction sets |
SSE4.1, SSE4.2, AVX 2.0, AVX-512 |
Scalability |
1S |
CPU configuration (max) |
1 |
Embedded options available |
Yes |
Export Control Classification Number (ECCN) |
5A992CN3 |
Commodity Classification Automated Tracking System (CCATS) |
G167599 |
Processor special features |
Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
Intel® Turbo Boost Technology |
2.0 |
Intel® Quick Sync Video Technology |
Yes |
Intel® InTru™ 3D Technology |
Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
Intel® AES New Instructions (Intel® AES-NI) |
Yes |
Enhanced Intel SpeedStep Technology |
Yes |
Intel Trusted Execution Technology |
Yes |
Intel® Memory Protection Extensions (Intel® MPX) |
Yes |
Intel® Turbo Boost Technology 2.0 frequency |
4.6 GHz |
Intel® Transactional Synchronization Extensions |
No |
Maximum Enclave Size Support for Intel® SGX |
0.5 GB |
Intel VT-x with Extended Page Tables (EPT) |
Yes |
Intel® Secure Key |
Yes |
Intel® OS Guard |
Yes |
Intel Clear Video Technology |
Yes |
Intel Software Guard Extensions (Intel SGX) |
Yes |
Intel 64 |
Yes |
Intel Virtualization Technology (VT-x) |
Yes |
Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
Intel® Boot Guard |
Yes |
Intel® Optane™ DC Persistent Memory Supported |
No |
Intel® vPro™ Platform Eligibility |
Yes |
Operational conditions |
Tjunction |
100 °C |
Technical details |
Supported memory types |
DDR4-SDRAM |
Launch date |
Q3'21 |
Status |
Launched |
Servicing status |
Baseline Servicing |
Logistics data |
Harmonized System (HS) code |
85423119 |
Packaging data |
Package type |
Retail box |
Weight & dimensions |
Processor package size |
37.5 x 37.5 mm |
Other features |
Maximum internal memory |
128 GB |
