Management features |
|
Switch type |
Managed |
|
Switch layer |
L2 |
|
Quality of Service (QoS) support |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
SFP module slots quantity |
2 |
|
Network |
|
Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|
10G support |
No |
|
Port mirroring |
Yes |
|
Full duplex |
Yes |
|
Link aggregation |
Yes |
|
Broadcast storm control |
Yes |
|
Rate limiting |
Yes |
|
Auto MDI/MDI-X |
Yes |
|
VLAN support |
Yes |
|
Number of VLANs |
4094 |
|
Data transmission |
|
MAC address table |
8000 entries |
|
Switching capacity |
20 Gbit/s |
|
Forwarding rate |
14.88 Mpps |
|
Store-and-forward |
Yes |
|
Packet buffer memory |
4.1 MB |
|
Security |
|
Security algorithms |
SNMP, SNMPv2 |
|
Queue scheduling algorithms |
SP, Weighted Round Robin (WRR) |
|
Design |
|
Product colour |
Black |
|
Housing material |
Metal |
|
Power |
|
Power source |
DC |
|
DC input voltage |
48 V |
|
Input current |
2.5 A |
|
Power consumption (max) |
120 W |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet (PoE) ports quantity |
8 |
|
Power over Ethernet (PoE) power per port |
30 W |
|
Total Power over Ethernet (PoE) budget |
110 W |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 45 °C |
|
Storage temperature (T-T) |
-40 - 85 °C |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Storage relative humidity (H-H) |
5 - 95% |
|
Weight & dimensions |
|
Width |
217.6 mm |
|
Depth |
108.5 mm |
|
Height |
27.8 mm |
|
Weight |
1.21 kg |
|
Packaging data |
|
Package weight |
1.3 kg |
