General Information |
Summary |
Data line surge protection Protects connected loads from surges, spikes, lightning, and other power disturbances.
Battery-protected and surge-only outlets Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment
LED status indicators Quickly understand unit and power status with visual indicators.
Audible Alarms Provides notification of changing utility power and UPS conditions.
Transformer-block spaced outlets Protect equipment with input transformer blocks without blocking access to other receptacles.
Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Battery replacement without tools Allows quick, easy battery replacement.
Cold-start capable Provides temporary battery power when the utility power is out.
Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Automatic restart of loads after UPS shutdown Automatically starts up the connected equipment upon the return of utility power.
Resettable circuit breakers Enables a quick recovery from overload events.
Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. UL, FCC, CE, C-Tick approvals. |
Features |
Output power capacity |
0.35 kVA |
Output power |
210 W |
Input frequency |
50/60 Hz |
Surge energy rating |
1020 J |
Audible alarm(s) |
Yes |
Battery |
Typical backup time at full load |
4.7 min |
Typical backup time at half load |
18.1 min |
Battery recharge time |
8 h |
Hot-swap battery |
Yes |
Design |
Product colour |
Beige |
Cable length |
1.8 m |
LED indicators |
Yes |
Safety |
UL/FCC/CE/C-Tick |
Certification |
FCC Part 68/TUV |
Operational conditions |
Operating temperature (T-T) |
0 - 40 °C |
Storage temperature (T-T) |
-15 - 45 °C |
Operating relative humidity (H-H) |
5 - 95% |
Storage relative humidity (H-H) |
5 - 95% |
Operating altitude |
0 - 3000 m |
Weight & dimensions |
Weight |
5.98 kg |
Package weight |
6.36 kg |
Logistics data |
Products per pallet |
80 pc(s) |
Other features |
Output connections |
3 x NEMA 5-15R |
Input connection type |
NEMA 5-15P |
Dimensions (WxDxH) |
91 x 284 x 165 mm |
Nominal output voltage |
120 V |
Nominal input voltage |
120 V |
Operating temperature (T-T) |
0 - 40 °F |
Package dimensions (WxDxH) |
175 x 357 x 263 mm |
Non-operating relative humidity (non-condensing) |
0 - 95% |
Weight (imperial) |
5.67 kg (12.5 lbs) |
