General Information |
|
Summary |
Power-saving outlets
- Automatically cuts power to idle equipment to conserve electricity.
Disconnected battery notification
- Warns when a battery is not available to provide backup power.
Boost and Trim Automatic Voltage Regulation (AVR)
- Gives higher application availability by correcting low and high voltage conditions without using the battery.
LCD graphics display
- Text and mimic diagrams that display modes of operation, system parameters and alarms. |
|
Features |
|
Output power capacity |
0.7 kVA |
|
Output power |
420 W |
|
Surge energy rating |
355 J |
|
Noise level |
40 dB |
|
Audible alarm(s) |
Yes |
|
Ports & interfaces |
|
AC outlet types |
NEMA 5-15R |
|
Ethernet LAN (RJ-45) ports |
2 |
|
Battery |
|
Battery technology |
Sealed Lead Acid (VRLA) |
|
Battery recharge time |
12 h |
|
Design |
|
Product colour |
Black |
|
Cable length |
1.83 m |
|
LED indicators |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-14 - 40 °C |
|
Operating relative humidity (H-H) |
0 - 95% |
|
Storage relative humidity (H-H) |
0 - 40% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 3000 m |
|
Certificates |
|
Certification |
FCC Part 15 Class B, FCC Part 68, NOM, UL 1778 |
|
Weight & dimensions |
|
Weight |
7.15 kg |
|
Packaging data |
|
Package weight |
7.95 kg |
|
Logistics data |
|
Harmonized System (HS) code |
85078000 |
|
Other features |
|
Output connections |
3 x NEMA 5-15R
3 x NEMA 5-15R |
|
Dimensions (WxDxH) |
91 x 310 x 190 mm |
|
Nominal output voltage |
120 V |
|
Nominal input voltage |
120 V |
|
Filtering |
Yes |
|
Package dimensions (WxDxH) |
138 x 442 x 252 mm |
