General Information |
Summary |
High density, double-conversion on-line power protection with scalable runtime
Includes : CD with software, Documentation CD, Installation guide, Removable support feet, USB cable, Warranty card. |
Features |
UPS topology |
Double-conversion (Online) |
Output power capacity |
2.2 kVA |
Output power |
1800 W |
Waveform |
Sine |
Input operation voltage (min) |
120 V |
Input operation voltage (max) |
120 V |
Input frequency |
40 - 70 Hz |
Output operation voltage (min) |
120 V |
Output operation voltage (max) |
120 V |
Output frequency |
50/60 Hz |
Surge energy rating |
340 J |
Crest factor |
3:1 |
Emergency Power Off (EPO) |
Yes |
Noise level |
55 dB |
Surge protection |
Yes |
Power protection features |
Overload |
Audible alarm(s) |
Yes |
Web-based management |
Yes |
Audible alarm modes |
Battery replacement |
Auto-restart |
Yes |
Ports & interfaces |
AC outlet types |
NEMA 5–20R, NEMA L5-20R |
Power plug |
NEMA 5-20P |
AC outlets quantity |
7 AC outlet(s) |
USB port |
Yes |
Serial interface |
Yes |
Serial interface type |
RJ-45 |
Ethernet LAN (RJ-45) ports |
2 |
SmartSlot |
Yes |
Battery |
Battery capacity |
306 VAh |
Battery life (max) |
5 year(s) |
Hot-swap battery |
Yes |
Automatic battery test |
Yes |
Cold start |
Yes |
Design |
Form factor |
Tower |
Product colour |
Black |
Cable length |
1.83 m |
Display type |
LCD |
LED indicators |
Status, Battery replacement |
International Protection (IP) code |
IP20 |
Certification |
CSA C22.2 No.107.3-05, ENERGY STAR (USA), FCC Part 15 Class A, UL 1778 |
Operational conditions |
Operating temperature (T-T) |
0 - 40 °C |
Storage temperature (T-T) |
-15 - 45 °C |
Operating relative humidity (H-H) |
0 - 95% |
Storage relative humidity (H-H) |
0 - 95% |
Operating altitude |
0 - 3000 m |
Non-operating altitude |
0 - 15000 m |
Technical details |
Sustainability certificates |
RoHS, ENERGY STAR |
Weight & dimensions |
Width |
85 mm |
Depth |
584 mm |
Height |
432 mm |
Weight |
25 kg |
Package width |
599 mm |
Package depth |
810 mm |
Package height |
246 mm |
Package weight |
30.8 kg |
Package type |
Box |
Packaging data |
Bracket |
Yes |
Cables included |
USB cable |
Quick installation guide |
Yes |
Warranty card |
Yes |
Software CD |
Yes |
Logistics data |
Products per pallet |
12 pc(s) |
