Features |
|
UPS topology |
Standby (Offline) |
|
Output power capacity |
0.55 kVA |
|
Output power |
300 W |
|
Waveform |
Pure sine |
|
Input operation voltage (min) |
110 V |
|
Input operation voltage (max) |
120 V |
|
Input frequency |
60 Hz |
|
Output operation voltage (min) |
115 V |
|
Output operation voltage (max) |
120 V |
|
Output frequency |
50/60 Hz |
|
Maximum current |
15 A |
|
Surge energy rating |
316 J |
|
Number of input phases |
1 |
|
EMI/RFI noise filtering |
Yes |
|
Surge protection |
Yes |
|
Surge protection features |
Telephone |
|
Audible alarm(s) |
Yes |
|
Ports & interfaces |
|
AC outlet types |
NEMA 5–15R |
|
Power plug |
NEMA 5-15P |
|
AC outlets quantity |
10 AC outlet(s) |
|
USB port |
Yes |
|
USB 2.0 ports quantity |
1 |
|
Modem (RJ-11) ports |
1 |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Battery |
|
Battery voltage |
12 V |
|
Typical backup time at full load |
1.2 min |
|
Typical backup time at half load |
5 min |
|
Cold start |
Yes |
|
Design |
|
Form factor |
Tower |
|
Product colour |
Black |
|
Housing material |
Acrylonitrile butadiene styrene (ABS) |
|
Cable length |
1.5 m |
|
LED indicators |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-15 - 45 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Operating altitude |
0 - 3048 m |
|
Certificates |
|
Compliance certificates |
RoHS |
|
Certification |
UL1778, CSA, NOM, FCC |
|
Packaging content |
|
Cables included |
USB cable |
|
Manual |
Yes |
|
Weight & dimensions |
|
Width |
110 mm |
|
Depth |
184.9 mm |
|
Height |
104.9 mm |
|
Weight |
1.8 kg |
|
Packaging data |
|
Package width |
144 mm |
|
Package depth |
275.8 mm |
|
Package height |
186.9 mm |
|
Package weight |
2.36 kg |
|
Logistics data |
|
Master (outer) case width |
286 mm |
|
Master (outer) case length |
591.8 mm |
|
Master (outer) case height |
394 mm |
|
Master (outer) case gross weight |
16.7 kg |
|
Products per master (outer) case |
8 pc(s) |
|
Master (outer) case GTIN (EAN/UPC) |
10037332211061 |
|
Country of origin |
Vietnam |
