StarTech Dual mSATA SSD to 2.5” SATA RAID Adapter Converter
|
|
Price: $25.00
Manufacturer:
StarTech
StarTech Dual mSATA SSD to 2.5” SATA RAID Adapter Converter - 2x mSATA SSD to 2.5in SATA Adapter with RAID and 7mm Open Frame Housing , TAA (25SAT22MSAT)
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
58123546
|
25SAT22MSAT
|
65030855617 |
Active
|
Details
|
General Information |
|
Summary |
Build a RAID array with two mSATA SSDs that can be installed into a single 2.5in SATA bay
Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support. |
|
Ports & interfaces |
|
Host interface |
SATA |
|
Output interface |
mSATA |
|
SATA revision |
3.0 |
|
Port multiplier |
Yes |
|
Design |
|
Internal |
Yes |
|
Product colour |
Black, Green |
|
Mean time between failures (MTBF) |
5101299 h |
|
Hot-swap |
No |
|
Certification |
CE, FCC |
|
Features |
|
Chipset |
JMicron JMS562 |
|
Data transfer rate (max) |
6 Gbit/s |
|
RAID levels |
0, 1, BIG, JBOD |
|
Plug and Play |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
-40 - 85 °C |
|
System requirements |
|
Windows operating systems supported |
Yes |
|
Mac operating systems supported |
Yes |
|
Linux operating systems supported |
Yes |
|
Technical details |
|
Compliance certificates |
RoHS |
|
Weight & dimensions |
|
Width |
70 mm |
|
Depth |
97 mm |
|
Height |
7 mm |
|
Weight |
39 g |
|
Packaging data |
|
Mounting brackets included |
Yes |
|
Quick installation guide |
Yes |
|
Package width |
143 mm |
|
Package depth |
175 mm |
|
Package height |
34 mm |
|
Package weight |
107 g |
|
Logistics data |
|
Harmonized System (HS) code |
84733020 |
|
Products per master (outer) case |
60 pc(s) |
|
Master (outer) case width |
382 mm |
|
Master (outer) case length |
498 mm |
|
Master (outer) case height |
322 mm |
|
