General Information |
|
Summary |
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. |
|
Features |
|
UPS topology |
Line-Interactive |
|
Output power capacity |
2.2 kVA |
|
Output power |
1920 W |
|
Waveform |
Sine |
|
Input operation voltage (min) |
82 V |
|
Input operation voltage (max) |
144 V |
|
Input frequency |
50/60 Hz |
|
Output operation voltage (min) |
120 V |
|
Output operation voltage (max) |
120 V |
|
Output frequency |
50/60 Hz |
|
Output voltage regulation |
5% |
|
Surge energy rating |
530 J |
|
Efficiency |
96% |
|
Noise level |
55 dB |
|
Ports & interfaces |
|
AC outlet types |
NEMA 5–15R, NEMA 5–20R |
|
AC outlets quantity |
8 AC outlet(s) |
|
USB port |
Yes |
|
Serial interface |
Yes |
|
Serial interface type |
RJ-45 |
|
Ethernet LAN (RJ-45) ports |
1 |
|
SmartSlot |
Yes |
|
Battery |
|
Battery technology |
Lithium-Ion (Li-Ion) |
|
Typical backup time at full load |
6 min |
|
Typical backup time at half load |
12 min |
|
Design |
|
Form factor |
Rackmount |
|
Product colour |
Black, Silver |
|
Rack capacity |
2U |
|
Display type |
LCD |
|
LED indicators |
Yes |
|
International Protection (IP) code |
IP20 |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-15 - 45 °C |
|
Operating relative humidity (H-H) |
0 - 95% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 7620 m |
|
Certificates |
|
Certification |
CSA C22.2 No 107.1, CULus, FCC part 15 class A, UL 1778, UL 1973 |
|
Weight & dimensions |
|
Width |
432.1 mm |
|
Depth |
683 mm |
|
Height |
86.1 mm |
|
Weight |
31.9 kg |
|
Packaging data |
|
Package width |
600 mm |
|
Package depth |
980.4 mm |
|
Package height |
254 mm |
|
Package weight |
39.2 kg |
