Features |
|
UPS topology |
Line-Interactive |
|
Output power capacity |
0.75 kVA |
|
Output power |
675 W |
|
Waveform |
Sine |
|
Input operation voltage (min) |
75 V |
|
Input operation voltage (max) |
154 V |
|
Output operation voltage (min) |
120 V |
|
Output frequency |
50/60 Hz |
|
Maximum current |
12 A |
|
Surge energy rating |
645 J |
|
Heat dissipation |
69 BTU/h |
|
Noise level |
40 dB |
|
Ports & interfaces |
|
USB port |
Yes |
|
Battery |
|
Battery technology |
Sealed Lead Acid (VRLA) |
|
Battery recharge time |
3 h |
|
Design |
|
Product colour |
Black |
|
Rack capacity |
2U |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-15 - 45 °C |
|
Operating relative humidity (H-H) |
0 - 95% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Weight & dimensions |
|
Width |
89 mm |
|
Depth |
490 mm |
|
Height |
432 mm |
|
Weight |
22.1 kg |
|
Packaging data |
|
Package width |
246 mm |
|
Package depth |
620 mm |
|
Package height |
589 mm |
|
Package weight |
26.5 kg |
|
Logistics data |
|
Warranty period |
3 year(s) |
