General Information |
|
Summary |
Built for business, with business-critical versatility
The versatile, highly reliable 1U ThinkSystem SR630 V2 2P rack server is designed to handle hybrid data center workloads, from IT infrastructure and HPC to cloud and hyperconverged. |
|
Processor |
|
Processor family |
Intel Xeon Silver |
|
Processor manufacturer |
Intel |
|
Processor model |
4309Y |
|
Processor frequency |
2.8 GHz |
|
Processor generation |
3rd Generation Intel® Xeon® Scalable |
|
Processor boost frequency |
3.6 GHz |
|
Processor cache |
12 MB |
|
Number of processors installed |
1 |
|
Maximum number of SMP processors |
2 |
|
Memory |
|
Internal memory |
32 GB |
|
Internal memory type |
DDR4-SDRAM |
|
Memory slots |
32x DIMM |
|
ECC |
Yes |
|
Memory clock speed |
3200 MHz |
|
Memory layout (slots x size) |
1 x 32 GB |
|
Storage |
|
Optical drive type |
No |
|
Graphics |
|
Maximum graphics card memory |
16 MB |
|
Network |
|
Wake-on-LAN ready |
Yes |
|
Ethernet LAN |
Yes |
|
Ports & interfaces |
|
USB 2.0 ports quantity |
1 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
|
VGA (D-Sub) ports quantity |
1 |
|
Design |
|
Chassis type |
Rack (1U) |
|
Product colour |
Black |
|
Rack mounting |
Yes |
|
Redundant fans support |
Yes |
|
Performance |
|
Performance management |
XClarity Enterprise |
|
Noise level |
56 dB |
|
BIOS type |
UEFI |
|
Trusted Platform Module (TPM) |
Yes |
|
Trusted Platform Module (TPM) version |
2.0 |
|
Software |
|
Operating system installed |
No |
|
Compatible operating systems |
Microsoft Windows Server 2016
Microsoft Windows Server 2019
Microsoft Windows Server 2022
Red Hat Enterprise Linux 7.9
Red Hat Enterprise Linux 8.2
Red Hat Enterprise Linux 8.3
SUSE Linux Enterprise Server 12 SP5
SUSE Linux Enterprise Server 12 Xen SP5
SUSE Linux Enterprise Server 15 SP2
SUSE Linux Enterprise Server 15 Xen SP2
VMware ESXi 6.7 U3
VMware ESXi 7.0 U2 |
|
Power |
|
Redundant power supply (RPS) support |
Yes |
|
Power supply |
750 W |
|
Number of redundant power supplies supported |
2 |
|
Number of redundant power supplies installed |
1 |
|
Operational conditions |
|
Storage temperature (T-T) |
-40 - 60 °C |
|
Storage relative humidity (H-H) |
8 - 90% |
|
Weight & dimensions |
|
Width |
440 mm |
|
Depth |
773 mm |
|
Height |
43 mm |
