CyberPower OL8KRT Smart App Online Series Sine Wave Double-Conversion UPS
|
|
Price: $9492.00
Manufacturer:
CyberPower
OL8KRT, 8 kVA, 8 kW, 200-240 V, 40-70 Hz, 3x NEMA L6-30R, 1x Hardwire Terminal Block, USB, RS-232, 12 V 9 Ah
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
58125702
|
OL8KRT
|
649532620227 |
Active
|
Details
|
General Information |
|
Summary |
The CyberPower Smart App Online OL8KRT is a 6U rack/tower UPS with double-conversion. It provides sine wave output to multiple types of critical IT infrastructure requiring seamless power protection. The OL8KRT is generator compatible and delivers consistent 200-240 V power with zero-transfer time. Automatic-bypass ensures connected equipment continues to operate seamlessly when an overload or internal fault is detected.
The OL8KRT features a removable LCD control panel to reposition it in a more convenient location (with optional DB-26 cable), and it has a RMCARD205 pre-installed network card. Smart-battery management charging technology increases battery life by up to 50%. Fast-charge technology helps replenish battery charge from 0-90% in five hours, regardless of the number of Extended Battery Modules (EBM) connected. The energy-saving GreenPower UPS™ ECO Mode allows the UPS to reach up to 96% efficiency to reduce power consumption and thermal dissipation.
This UPS can use the BP240V30ART3U or BP240VL3U01 extended battery module for more runtime. The OL6KRT comes with a three-year warranty (including batteries) and a $300,000 connected equipment guarantee.
Double-Conversion Topology
Provides consistent, clean, and nearly perfect sine wave output power, regardless of the condition of input power. UPS systems with this technology operate on isolated DC power 100% of the time and have a zero-transfer time because they electronically switch to battery (vs. using relays which can take 4-12 ms to switch). Double-conversion UPS systems are designed for high-availability applications, precise output voltage regulation (±2%), generator set compatibility, environments with poor power quality, and other sensitive electronic equipment.
Sine Wave Output Provides power protection to ENERGY STAR® 6.0 systems with Active PFC power supplies.
Removable LCD Control Panel
Panel displays 24 UPS status readings and allows configuration of 27 operation settings. The onboard event log will record and display the five most recent UPS system events. The LCD control panel can be removed and mounted in a more convenient location, up to ten feet away from the UPS (with optional DB-26 cable). Users can manage, setup, and control various operation settings, can scroll through multiple UPS status readings, and can run select UPS diagnostic tests.
Multiple Language Options
The LCD control panel can be configured to English, Spanish, French, or German for use in multiple countries.
Extended Battery Module (EBM)
Add runtime by connecting more EBMs. The Smart App Online series of UPS systems allow for up to ten EBMs to be connected in a daisy-chain.
Fast Charge Technology
Enables Smart App Online UPS systems with multiple EBMs to charge batteries from 0-90% capacity in five hours. This is possible thanks to the built-in charger in each EBM.
Smart Battery Management (SBM)
Extends the service life of Smart App Online UPS batteries and reduces excessive heat during charge cycles by using a three-stage charging process. The first stage charges the battery to full capacity. The second stage enters float mode. The third stage turns the charger OFF to allow the batteries to naturally discharge (rest) for up to 27 days or until they reach a low-voltage set point. SBM continuously monitors the UPS to restart the charge cycle as needed, ensuring that runtimes are maintained.
GreenPower UPS™ ECO Mode
Improves UPS efficiency up to 96% to reduce electrical and cooling costs.
Hot-Swappable Batteries
Eliminate downtime related to UPS maintenance for continuous power availability.
Generator Compatible
Mode of operation in which the UPS disregards rapid changes in input frequency like those found in the output waveform of some generator sets. This allows the UPS to continue to operate in normal Online Mode vs. switching to Battery Mode when the power source is a generator set.
Converter Mode
Provides the ability to set the UPS output frequency (50 Hz or 60 Hz), regardless of the input frequency. This is beneficial where the connected equipment must operate on a different frequency than provided by local electric utility.
Local and Remote Management
Monitor and manage the UPS system locally via USB or serial connection, or remotely via the pre-installed RMCARD205 network card. Access UPS status, configuration settings, event logs, and status records, and more. User can also setup email notifications.
Rack or Tower Installation
All the hardware accessories to rack mount the UPS in a standard 4-post 19” rack, or install as a tower unit, is included at no extra cost.
PowerPanel® Business Edition Software
A robust and feature rich power monitoring and management tool for physical or virtual environments, PowerPanel Business Edition offers local (Agent) or remote (Client) functionality to automate graceful shutdown of IT equipment. Installing PowerPanel Business Edition Center provides centralized monitoring and management of PPBE Agents and Clients on the local network in addition to all CyberPower devices. PPBE is FREE for download on the Downloads tab above.
Three-Year Warranty
CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date.
Connected Equipment Guarantee
CyberPower will repair or replace properly connected equipment if it is damaged by a power surge. |
|
Features |
|
UPS topology |
Double-conversion (Online) |
|
Output power capacity |
8 kVA |
|
Output power |
8000 W |
|
Waveform |
Sine |
|
Input operation voltage (min) |
120 V |
|
Input operation voltage (max) |
280 V |
|
Input frequency |
40 - 70 Hz |
|
Output operation voltage (min) |
200 V |
|
Output operation voltage (max) |
240 V |
|
Output frequency |
50/60 Hz |
|
Surge energy rating |
2430 J |
|
Transfer time (Line Mode to Battery Mode) |
0 ms |
|
Efficiency (ECO mode) |
96% |
|
Input power factor |
0.99 |
|
Output power factor |
1 |
|
Crest factor |
3:1 |
|
ECO mode |
Yes |
|
Emergency Power Off (EPO) |
Yes |
|
Overload capacity (1 minute) |
125% |
|
Overload capacity (10 seconds) |
130% |
|
EMI/RFI noise filtering |
Yes |
|
Noise level |
65 dB |
|
Power protection features |
Overload, Short circuit |
|
Audible alarm(s) |
Yes |
|
Audible alarm modes |
Alarm when on battery, Fault, Low battery alarm, Overload alarm |
|
Ports & interfaces |
|
AC outlet types |
NEMA L6-30R, Terminal |
|
AC outlets quantity |
4 AC outlet(s) |
|
USB port |
Yes |
|
USB 2.0 ports quantity |
1 |
|
USB port type |
USB Type-B |
|
Serial interface |
Yes |
|
Serial interface type |
RS-232 |
|
RS-232 ports |
1 |
|
Modem (RJ-11) ports |
2 |
|
Ethernet LAN (RJ-45) ports |
2 |
|
Emergency Power Off (EPO) connector |
Yes |
|
Battery |
|
Battery technology |
Sealed Lead Acid (VRLA) |
|
Battery capacity |
9 Ah |
|
Battery voltage |
12 V |
|
Number of batteries supported |
20 |
|
Typical backup time at full load |
4.7 min |
|
Typical backup time at half load |
12 min |
|
Battery recharge time(90%) |
5 h |
|
Hot-swap battery |
Yes |
|
Cold start |
Yes |
|
Design |
|
Form factor |
Rackmount/Tower |
|
Product colour |
Black |
|
Housing material |
Steel |
|
Rack capacity |
6U |
|
Display type |
LCD |
|
LED indicators |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 45 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 15000 m |
|
Certificates |
|
Compliance certificates |
RoHS |
|
Packaging content |
|
Rack mount kit |
Yes |
|
Cables included |
Phone (RJ-11), Serial, USB cable |
|
Quick installation guide |
Yes |
|
Safety regulation & standards |
|
Safety |
UL 1778 5th Ed., CSA C22.2 NO.107.3-05, FCC 5 A |
|
Weight & dimensions |
|
Width |
433 mm |
|
Depth |
660 mm |
|
Height |
266 mm |
|
Weight |
103 kg |
|
Packaging data |
|
Rubber feet |
Yes |
|
