General Information |
|
Summary |
Provides 8 ports 1G/2.5G with 4 PoE+ ports and 4 Ultra60 PoE++ ports making it a perfect switch for WiFi 6 AP connectivity, IP surveillance and more.
Multi-Gigabit Ethernet
8 ports provide up to 2.5 Gbps of dedicated, non-blocking bandwidth each.
PoE Support
4 Ultra60 PoE++ and 4 PoE+ ports provide a total of 230W of power so you can power and connect your devices with a single wire.
Advanced PoE Controls
Manage PoE prioritization, scheduling, power limit per port, and more for simple control over all PoE-powered devices.
Non-Blocking Switching
40Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices.
Fanless Design
Silent operation makes this switch perfect for noise-sensitive environments.
Versatile Mounting Options
Install your switch on your desktop, or mount it to your wall or rack with the hardware provided in the box. |
|
Management features |
|
Switch type |
Managed |
|
Switch layer |
L2/L3 |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
Network |
|
Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
|
10G support |
No |
|
Copper ethernet cabling technology |
100BASE-T, 1000BASE-T |
|
Port mirroring |
Yes |
|
Full duplex |
Yes |
|
Flow control support |
Yes |
|
Link aggregation |
Yes |
|
Rate limiting |
Yes |
|
VLAN support |
Yes |
|
Virtual LAN features |
Port-based VLAN, Tagged VLAN |
|
Number of VLANs |
64 |
|
Data transmission |
|
MAC address table |
16000 entries |
|
Switching capacity |
40 Gbit/s |
|
Store-and-forward |
Yes |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
12000 |
|
Packet buffer memory |
1.5 MB |
|
Security |
|
DHCP features |
DHCP client |
|
IGMP snooping |
Yes |
|
Password protection |
Yes |
|
Queue scheduling algorithms |
Strict Priority Queue (SPQ), Weighted Round Robin (WRR) |
|
Multicast features |
|
Multicast support |
Yes |
|
Number of multicast groups filtered |
128 |
|
Design |
|
Rack mounting |
No |
|
Stackable |
No |
|
Product colour |
Grey |
|
Housing material |
Metal |
|
LED indicators |
Yes |
|
Performance |
|
Mean time between failures (MTBF) |
373644 h |
|
Power |
|
Power source |
PoE |
|
Power supply included |
Yes |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet plus (PoE+) ports quantity |
8 |
|
Total Power over Ethernet (PoE) budget |
230 W |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 3000 m |
|
Weight & dimensions |
|
Width |
210 mm |
|
Depth |
140 mm |
|
Height |
40 mm |
|
Weight |
900 g |
|
Certificates |
|
Certification |
CE
FCC 15 B
CE/EN55032/24
CSA
VCCI
ACMA
KC
CCC
BSMI |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
