APC Rack PDU, Basic, 0U/1U, 208V, 8.6kW, (3) C19
|
|
Regularly: $389.00
On Sale: $373.44
Sale Ends:
April 20th, 2025
Manufacturer:
APC
0U/1U, 3xC19, 200-240V, 50/60Hz, 30A
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
58214926
|
AP6037A
|
731304327837 |
Active
|
Details
|
General Information |
|
Summary |
Low Cost Power Distribution
Provides a number of outlets to bring power to rack equipment at an affordable price.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 17.3kW using a single branch whip.
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
|
|
Design |
|
PDU types |
Basic |
|
Rack capacity |
0U/1U |
|
Type |
Three-phase |
|
Mounting |
Horizontal/Vertical |
|
Product colour |
Black |
|
Ports & interfaces |
|
AC outlets quantity |
3 AC outlet(s) |
|
AC outlet types |
C19 coupler |
|
Power plug |
NEMA L15-30P |
|
Features |
|
Cable length |
3.65 m |
|
Power |
|
Nominal input voltage |
200-240 V |
|
Maximum current |
30 A |
|
AC input frequency |
50/60 Hz |
|
Output voltage |
200-240 V |
|
Load capacity |
8600 VA |
|
Power protection features |
Over current |
|
Certificates |
|
Compliance certificates |
RoHS |
|
Certification |
UL/C-UL, PSE |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-15 - 60 °C |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Storage relative humidity (H-H) |
5 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 15000 m |
|
Weight & dimensions |
|
Width |
388.1 mm |
|
Depth |
125.7 mm |
|
Height |
43.6 mm |
|
Weight |
3.06 kg |
|
Packaging data |
|
Package weight |
5.06 kg |
|
Package width |
454.9 mm |
|
Package depth |
331.9 mm |
|
Package height |
195 mm |
|
