General Information |
|
Summary |
The M4250 series ranges from 8 to 48 ports with a variety of PoE, PoE+ and Ultra90 PoE++ options. In addition, uplink options include 1G for audio installations or standalone video installations as well as 10G uplinks for larger scale video deployments. The M4250 series also includes 12-port multi-Gigabit Ethernet and 16-port 1G/10G fiber models for plug-and-play aggregation in a totally automated star topology. |
|
Management features |
|
Switch type |
Managed |
|
Switch layer |
L2/L3/L4 |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
40 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
SFP+ module slots quantity |
8 |
|
Console port |
RJ-45/USB Type-C |
|
Network |
|
Networking standards |
IEEE 802.1Qav, IEEE 802.1ak, IEEE 802.1as, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt |
|
10G support |
Yes |
|
VLAN support |
Yes |
|
Virtual LAN features |
Private VLAN |
|
Number of VLANs |
4000 |
|
Data transmission |
|
MAC address table |
16000 entries |
|
Switching capacity |
240 Gbit/s |
|
Throughput |
178.56 Mpps |
|
Latency (1 Gbps) |
2.78 µs |
|
Latency (10 Gbps) |
0.73 µs |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
12000 |
|
Packet buffer memory |
32 MB |
|
Security |
|
DHCP features |
DHCP relay, DHCP server, DHCPv6 server |
|
IGMP snooping |
Yes |
|
Security algorithms |
SNMP |
|
Multicast features |
|
Multicast support |
Yes |
|
Design |
|
Rack mounting |
Yes |
|
Form factor |
1U |
|
Product colour |
Black |
|
LED indicators |
Yes |
|
Performance |
|
Noise level |
69 dB |
|
Power |
|
Power source |
PoE |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet plus (PoE+) ports quantity |
40 |
|
Total Power over Ethernet (PoE) budget |
960 W |
|
Weight & dimensions |
|
Width |
440 mm |
|
Depth |
440 mm |
|
Height |
43.2 mm |
|
Weight |
6.31 kg |
|
Packaging content |
|
User guide |
Yes |
|
Rack mount kit |
Yes |
