General Information |
|
Summary |
The CyberPower Adaptive SinewaveTM Series offers users from home to SMEs clean and stable battery backup while the featured RJ11/RJ45 port ensures phone, fax, and modem lines are protected from surges. With Automatic Voltage Regulation (AVR) stabilizes the AC signal and maintains a safe voltage, this allows the UPS to maintain safe power levels for the connected equipment without resorting to battery power. The multifunction LCD readout provides immediate access to precise information of critical power/battery condition. The included PowerPanel® Personal Edition management software showcases the featured rich abilities such as input/output power voltage readings, self-diagnostics, scheduled-shutdown, and approximate battery backup time. With the Energy-Saving Technology, the Adaptive SinewaveTM Series can save up to 75% of electricity therefore save your electricity expenses. |
|
Features |
|
UPS topology |
Standby (Offline) |
|
Output power capacity |
0.9 kVA |
|
Output power |
540 W |
|
Waveform |
Pure sine |
|
Input operation voltage (min) |
170 V |
|
Input operation voltage (max) |
270 V |
|
Input frequency |
50/60 Hz |
|
Output frequency |
50/60 Hz |
|
Maximum current |
10 A |
|
Surge energy rating |
405 J |
|
Response time |
4 ms |
|
Output voltage Total Harmonic Distortion (THD) |
10% |
|
EMI/RFI noise filtering |
Yes |
|
Surge protection |
Yes |
|
Surge protection features |
Fax, Modem, Network, Telephone |
|
Power protection features |
Over power, Over voltage, Overload, Short circuit |
|
Audible alarm(s) |
Yes |
|
Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm |
|
Auto-restart |
Yes |
|
Ports & interfaces |
|
Power plug |
C14 coupler |
|
AC outlets quantity |
6 AC outlet(s) |
|
USB 2.0 ports quantity |
1 |
|
Modem (RJ-11) ports |
1 |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Battery |
|
Battery technology |
Sealed Lead Acid (VRLA) |
|
Battery voltage |
230 V |
|
Number of batteries supported |
1 |
|
Typical backup time at full load |
1 min |
|
Typical backup time at half load |
7 min |
|
Battery recharge time |
8 h |
|
Design |
|
Form factor |
Tower |
|
Product colour |
Black |
|
Housing material |
Plastic |
|
Cable length |
1.83 m |
|
Display type |
LCD |
|
LED indicators |
Operation |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
15 - 45 °C |
|
Operating relative humidity (H-H) |
0 - 95% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 15000 m |
|
Certificates |
|
Certification |
CE, EAC, RCM |
|
Weight & dimensions |
|
Width |
100 mm |
|
Depth |
230 mm |
|
Height |
275 mm |
|
Weight |
6.6 kg |
|
Packaging data |
|
Package width |
195 mm |
|
Package depth |
365 mm |
|
Package height |
335 mm |
|
Package weight |
7.8 kg |
|
Logistics data |
|
Harmonized System (HS) code |
8504408590 |
|
Country of origin |
China |
|
Other features |
|
Interface |
USB |
|
Nominal output voltage |
230 V |
|
Nominal input voltage |
165-265 V |
|
Compatible operating systems |
Windows 7/Vista/XP/2000/Server 2003, Linux |
|
Operating temperature (T-T) |
32 - 104 °F |
|
Suitable for use in country/location |
Europe |
