General Information |
|
Summary |
iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Intel® Ethernet Power Management
Intel® Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance |
|
Ports & interfaces |
|
Connectivity technology |
Wired |
|
Host interface |
PCI Express |
|
Interface |
Fiber |
|
Fiber ports quantity |
4 |
|
Fiber optic connector |
SFP+ |
|
PCI version |
3.0 |
|
Network |
|
Maximum data transfer rate |
1000 Mbit/s |
|
Ethernet LAN |
Yes |
|
Ethernet interface type |
Gigabit Ethernet |
|
Ethernet LAN data rates |
10,1000 Mbit/s |
|
LAN controller |
Intel® XL710-BM1 |
|
Design |
|
Internal |
Yes |
|
Component for |
PC/Server |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
|
Other features |
|
Cable type |
SFP+ Direct Attach Copper
10GBASE-SR and 10GBASE-LR Physical Media |
|
Intel Virtual Machine Device Queues (VMDq) |
Yes |
|
PCI-SIG* SR-IOV Capable |
Yes |
|
On-chip QoS and Traffic Management |
Yes |
|
Intel Flexible Port Partitioning |
Yes |
|
Speed & slot width |
8.0 GT/s, x8 Lane |
|
Intelligent Offloads |
Yes |
|
iWARP/RDMA |
No |
|
Intel Ethernet Power Management |
Yes |
|
Intel Data Direct I/O Technology |
Yes |
|
Intel Virtualization Technology for Connectivity (VT-c) |
Yes |
|
Interface type |
PCIe v3.0 (8.0 GT/s) |
|
Product type |
Network Interface Card |
|
Processor family |
700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE) |
|
Export Control Classification Number (ECCN) |
5A991 |
|
Commodity Classification Automated Tracking System (CCATS) |
NA |
|
Controller type |
Intel(R) Ethernet Controller X710 |
|
Cabling type |
SFP+ Direct Attach Copper
10GBASE-SR and 10GBASE-LR Physical Media |
|
Bracket height |
OCP 3.0 |
|
Target market |
Artificial Intelligence, High Performance Computing |
|
Storage Over Ethernet |
iSCSI, NFS |
|
Launch date |
Q4'19 |
|
Network interface card cable medium |
Copper |
|
Network interface card type |
Server |
|
Product brief URL |
https://www.intel.com/content/www/us/en/products/docs/network-io/ethernet/network-adapters/ethernet-network-adapter-x710-for-ocp-3-brief.html |
|
Status |
Launched |
|
Product series |
700 Series Network Adapters (up to 40GbE) |
