General Information |
|
Summary |
The NETGEAR 5-port Multi-Gigabit Unmanaged Switch helps businesses cost-effectively expand their network with Multi-Gigabit speeds. The MS305 Multi-Gigabit Ethernet Switch comes with 5 2.5G ports in a metal case and can be placed on a desk or wall-mountable. This switch is fanless, energy?efficient, built to last, and rigorously tested to provide the reliability businesses need. 802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks. |
|
Management features |
|
Switch type |
Unmanaged |
|
Quality of Service (QoS) support |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
5 |
|
Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
|
Network |
|
Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3x |
|
Full duplex |
Yes |
|
Half duplex |
Yes |
|
Auto MDI/MDI-X |
Yes |
|
Head-of-line (HOL) blocking |
Yes |
|
Ethernet LAN data rates |
100,1000,2500 Mbit/s |
|
Cable length detection |
Yes |
|
Data transmission |
|
Latency (1 Gbps) |
2458 µs |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9720 |
|
Packet buffer memory |
1 MB |
|
Design |
|
Rack mounting |
No |
|
Stackable |
No |
|
Product colour |
Black |
|
Housing material |
Metal |
|
LED indicators |
Yes |
|
Wall mountable |
Yes |
|
Number of fans |
0 fan(s) |
|
Performance |
|
Noise level |
0 dB |
|
Fanless |
Yes |
|
Mean time between failures (MTBF) |
1401743 h |
|
Power |
|
Power source |
DC |
|
Power supply included |
Yes |
|
DC input voltage |
12 V |
|
Input current |
1 A |
|
Input voltage |
12 V |
|
Power consumption (typical) |
4.6 W |
|
Power consumption (max) |
9.24 W |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
No |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Weight & dimensions |
|
Width |
158 mm |
|
Depth |
101 mm |
|
Height |
29 mm |
|
Weight |
480 g |
|
Certificates |
|
Compliance certificates |
CCC, Low Voltage Directive (LVD) |
