Processor |
Processor manufacturer |
AMD |
Processor socket |
Socket AM5 |
Compatible processor series |
AMD Ryzen™ 3, AMD Ryzen™ 5 |
Maximum number of SMP processors |
1 |
Memory |
Supported memory types |
DDR5-SDRAM |
Number of memory slots |
4 |
Maximum internal memory |
32 GB |
Memory slots type |
DIMM |
Memory voltage |
1.1 V |
ECC сompatibility |
ECC & Non-ECC |
Supported memory clock speeds |
3600,5200 MHz |
Supported memory clock speed (max) |
5200 MHz |
Storage controllers |
Supported storage drive interfaces |
M.2, SATA III |
RAID support |
Yes |
RAID levels |
0, 1, 10 |
Graphics |
On-board graphics card model |
Aspeed AST2600 |
Internal I/O |
USB 2.0 connectors |
0 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors |
0 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors |
0 |
Number of SATA III connectors |
4 |
ATX Power connector (24-pin) |
Yes |
EPS power connector (8-pin) |
Yes |
Number of COM connectors |
1 |
TPM connector |
Yes |
Rear panel I/O ports |
USB 2.0 ports quantity |
0 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
Ethernet LAN (RJ-45) ports |
2 |
VGA (D-Sub) ports quantity |
1 |
HDMI ports quantity |
1 |
DVI-D ports quantity |
0 |
IPMI LAN (RJ-45) port |
Yes |
Serial ports quantity |
1 |
Network |
Wi-Fi |
No |
Ethernet LAN |
Yes |
Features |
Component for |
Server |
Motherboard form factor |
micro ATX |
Motherboard chipset family |
AMD |
Motherboard chipset |
AMD B650 Express |
PC health monitoring |
CPU, Fan, Voltage |
Expansion slots |
PCI Express x4 (Gen 4.x) slots |
1 |
BIOS |
BIOS type |
UEFI AMI |
BIOS memory size |
256 Mbit |
ACPI version |
6.4 |
System Management BIOS (SMBIOS) version |
3.5 |
Operational conditions |
Storage temperature (T-T) |
-40 - 70 °C |
Operating temperature (T-T) |
10 - 35 °C |
Operating relative humidity (H-H) |
20 - 90% |
Weight & dimensions |
Width |
243.8 mm |
Depth |
243.8 mm |
