Intel Core i5-13500 2.5GHz 6P+8E S1700 Processor

Home :: CPU/Processors :: Intel Desktop CPUs ::


Regularly: $356.00
On Sale: $325.95    Sale Ends: June 16th, 2024

Manufacturer: Intel

Intel® Core™ i5-13500 Processor (24M Cache, up to 4.80 GHz)

Availability
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
Product # Manufacturer # UPC # Status
58789786 BX8071513500 5032037260251 Active

Details

General Information
Summary Intel Core i5-13500 Desktop Processor, 14 cores (6 P-cores + 8 E-cores), 24MB Cache, up to 4.8 GHz
Processor
Processor family Intel® Core™ i5
Processor cores 14
Processor socket LGA 1700
Box Yes
Cooler included Yes
Processor manufacturer Intel
Processor model i5-13500
Processor operating modes 64-bit
Processor generation 13th gen Intel® Core™ i5
Processor threads 20
Performance cores 6
Efficient cores 8
Processor boost frequency 4.8 GHz
Performance-core boost frequency 4.8 GHz
Performance-core base frequency 2.5 GHz
Efficient-core boost frequency 3.5 GHz
Efficient-core base frequency 1.8 GHz
Processor cache 24 MB
Processor cache type Smart Cache
Processor base power 65 W
Maximum turbo power 154 W
Bus type DMI4
Maximum number of DMI lanes 8
Memory bandwidth supported by processor (max) 76.8 GB/s
Processor codename Raptor Lake
Processor ARK ID 230580
Memory
Memory channels Dual-channel
Maximum internal memory supported by processor 192 GB
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
ECC Yes
Non-ECC Yes
Memory bandwidth (max) 76.8 GB/s
Graphics
On-board graphics card Yes
Discrete graphics card No
On-board graphics card model Intel UHD Graphics 770
Discrete graphics card model Not available
On-board graphics card outputs supported Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card base frequency 300 MHz
On-board graphics card dynamic frequency (max) 1550 MHz
Number of displays supported (on-board graphics) 4
On-board graphics card DirectX version 12.0
On-board graphics card OpenGL version 4.5
On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz
On-board graphics card ID 0x4680
Number of execution units 32
Multi-Format Codec Engines 2
Features
Execute Disable Bit Yes
Idle States Yes
Thermal Monitoring Technologies Yes
Market segment Desktop
Use conditions PC/Client/Tablet, Workstation
Maximum number of PCI Express lanes 20
PCI Express slots version 5.0, 4.0
PCI Express configurations 1x16+1x4, 2x8+1x4
Supported instruction sets SSE4.1, SSE4.2, AVX 2.0
Scalability 1S
CPU configuration (max) 1
Embedded options available Yes
Direct Media Interface (DMI) Revision 4.0
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® Turbo Boost Technology 2.0
Intel® Quick Sync Video Technology Yes
Intel® Clear Video HD Technology (Intel® CVT HD) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Enhanced Intel SpeedStep Technology Yes
Intel Trusted Execution Technology Yes
Intel® Speed Shift Technology Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Intel® Control-flow Enforcement Technology (CET) Yes
Intel® Thread Director Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel® Secure Key Yes
Intel® Active Management Technology (Intel® AMT) Yes
Intel Stable Image Platform Program (SIPP) Yes
Intel® OS Guard Yes
Intel 64 Yes
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Turbo Boost Max Technology 3.0 No
Intel® Boot Guard Yes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Volume Management Device (VMD) Yes
Mode-based Execute Control (MBE) Yes
Intel® vPro™ Platform Eligibility Yes
Intel® Standard Manageability (ISM) Yes
Intel® One-Click Recovery Yes
Intel® Remote Platform Erase (RPE) Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) Yes
Intel vPro® Enterprise Platform Eligibility Yes
Intel® Threat Detection Technology (TDT) Yes
Intel® Hardware Shield Eligibility Yes
Intel® Total Memory Encryption - Multi Key Yes
Intel vPro® Essentials Platform Eligibility Yes
Operational conditions
Tjunction 100 °C
Technical details
OpenCL version 3.0
Target market Gaming
Launch date Q1'23
Status Launched
Logistics data
Harmonized System (HS) code 8542310001
Packaging data
Package type Retail box
Weight & dimensions
Processor package size 45 x 37.5 mm
Other features
L2 cache 11776 KB
Maximum internal memory 192 GB
Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1
