General Information |
|
Summary |
An all-in-one edge storage solution
The compact 1U 4-bay Synology RackStation RS822+/RS822RP+ with its storage and connectivity expandability coupled with the powerful Synology DiskStation Manager (DSM) operating system is an ideal edge storage solution for branch offices and small and medium-sized businesses.
Built for reliability
RS822+/RS822RP+ comes with four Gigabit RJ-45 ports which can be bonded with Link Aggregation to enable automatic network failover and load balancing.
Two RS822+/RS822RP+ units can be paired using Synology High Availability to form a reliable active/passive server cluster, maximizing service uptime.
Furthermore, the RS822RP+ features a redundant power supply for an extra edge in service continuity.
Room for expansion
Easily adjust the RS822+/RS822RP+ to match your usage environment, whether it needs performance, faster networking, or higher storage capacity.
All-in-one data management platform
The RS822+/RS822RP+ is designed to support small deployments in tackling common applications such as file management, data backup, and surveillance.
Edge storage for distributed teams
Provide secure and convenient cross-platform file access, sharing, and synchronization across multiplelocations.
Multi-endpoint data protection
Design an effective backup strategy to maximize system availability with a host of native and license-free solutions.
Smart surveillance for small deployments
Leverage flexible deployment options, intuitive management capabilities, and advanced video analytics to secure your premises.
Works best with Synology drives
Enjoy high sustained performance and reliability with enterprise-grade drives designed for Synology NAS and featuring built-in data protection.
Powered by Synology DSM
Take advantage of a whole host of native productivity, management, and security solutions available on the web-based DSM operating system. |
|
Processor |
|
Processor family |
AMD Ryzen |
|
Processor manufacturer |
AMD |
|
Processor model |
V1500B |
|
Processor frequency |
2.2 GHz |
|
Processor cores |
4 |
|
Number of processors installed |
1 |
|
Memory |
|
Internal memory |
2 GB |
|
Internal memory type |
DDR4-SDRAM |
|
Maximum internal memory |
32 GB |
|
Memory slots |
2x SO-DIMM |
|
ECC |
Yes |
|
Memory layout (slots x size) |
1 x 2 GB |
|
Storage |
|
RAID support |
Yes |
|
Optical drive type |
No |
|
Supported HDD sizes |
3.5" |
|
SSD size |
2.5" |
|
Internal drive bays |
4 |
|
Graphics |
|
On-board graphics card model |
Not available |
|
Network |
|
Ethernet LAN |
Yes |
|
Cabling technology |
10/100/1000Base-T(X) |
|
Ethernet interface type |
Gigabit Ethernet |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
4 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
|
eSATA ports quantity |
1 |
|
Expansion slots |
|
PCI Express x8 (Gen 3.x) slots |
1 |
|
Design |
|
Chassis type |
Rack (1U) |
|
Product colour |
Black, Grey |
|
Performance |
|
Noise level |
38.8 dB |
|
Power |
|
Redundant power supply (RPS) support |
Yes |
|
Power supply |
150 W |
|
Number of redundant power supplies supported |
2 |
|
Power supply input voltage |
100 - 240 V |
|
Power supply input frequency |
50/60 Hz |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 35 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Certificates |
|
Certification |
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
UL |
|
Sustainability |
|
Sustainability certificates |
RoHS |
|
Weight & dimensions |
|
Width |
480 mm |
|
Depth |
518.6 mm |
|
Height |
44 mm |
|
Weight |
8 kg |
