General Information |
|
Summary |
NETGEAR brings the first Unmanaged
Multi-Gigabit PoE++ switch MS108UP with 60Watts per port Ultra60 PoE++ technology, ideal for powerful PoE++ installations with PoE budgets up to 230W, a compact size, plug-and-play
installation, and reliable performance at affordable prices. The new model MS108UP supports 2.5 Gigabit speed connectivity and Power-Over-Ethernet (PoE) that can provide up to 60W/port. The new switch model can power devices such as VoIP phones, surveillance IP cameras, wireless access
points and many other applications. This new Unmanaged switch provides PoE Auto-Balance to help automatically balance the PoE power based on the device needs independent of PoE class detected. With the growing deployment of applications and an allin-one solution, providing multi-speed and high power to these applications would be ideal. |
|
Management features |
|
Switch type |
Unmanaged |
|
Quality of Service (QoS) support |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
|
2.5G Ethernet (copper) ports quantity |
8 |
|
Network |
|
Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
|
10G support |
No |
|
Full duplex |
Yes |
|
Half duplex |
Yes |
|
Auto MDI/MDI-X |
Yes |
|
Head-of-line (HOL) blocking |
Yes |
|
Ethernet LAN data rates |
100,1000,2500 Mbit/s |
|
Auto-sensing |
Yes |
|
VLAN support |
Yes |
|
Number of VLANs |
64 |
|
Data transmission |
|
MAC address table |
16000 entries |
|
Switching capacity |
40 Gbit/s |
|
Latency (1 Gbps) |
3.593 µs |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
12000 |
|
Packet forwarding rate (1 Gbps) |
1488000 pps |
|
Packet buffer memory |
1.5 MB |
|
Design |
|
Rack mounting |
No |
|
Housing material |
Metal |
|
Wall mountable |
Yes |
|
Number of fans |
0 fan(s) |
|
Electromagnetic compatibility |
CE, FCC part 15 Class B, ISED, VCCI, KC, CCC, BSMI, RCM |
|
Performance |
|
Fanless |
Yes |
|
Mean time between failures (MTBF) |
373643.7 h |
|
Power |
|
Power source |
DC |
|
Power supply included |
Yes |
|
DC input voltage |
54 V |
|
Input current |
4.7 A |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet plus (PoE+) ports quantity |
8 |
|
Total Power over Ethernet (PoE) budget |
230 W |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Operating altitude |
0 - 3000 m |
|
Heat dissipation |
923.49 BTU/h |
|
Weight & dimensions |
|
Width |
210 mm |
|
Depth |
140 mm |
|
Height |
40 mm |
|
Weight |
900 g |
|
Certificates |
|
Certification |
CB, CSA, CCC, BSMI, RCM |
