General Information |
|
Summary |
EnGenius Fit 802.11ax 2×2 Managed Dual Band Wireless Indoor Access Point
EnGenius Fit6 2x2 Lite Managed Indoor Wireless Access Point offers advanced 802.11ax technology, granting users incredibly speedy and efficient performance with a maximum theoretical speed of 574 Mbps on the 2.4GHz frequency and an incredible 2,400Mbps on 5GHz frequency! Furthermore it's safeguarded by top-tier WPA3/WPA2PSK AES encryption protocols for unparalleled security. security.
|
|
Features |
|
2.4 GHz |
Yes |
|
5 GHz |
Yes |
|
Maximum data transfer rate |
2400 Mbit/s |
|
Maximum data transfer rate (2.4 GHz) |
574 Mbit/s |
|
Maximum data transfer rate (5 GHz) |
2400 Mbit/s |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Networking standards |
IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g |
|
MIMO |
Yes |
|
MIMO type |
Multi User MIMO |
|
VLAN support |
Yes |
|
Quality of Service (QoS) support |
Yes |
|
Security |
|
Security algorithms |
WPA2-Enterprise, WPA3 |
|
MAC address filtering |
Yes |
|
IGMP snooping |
Yes |
|
Protocols |
|
Management protocols |
SNTP |
|
Management features |
|
Web-based management |
Yes |
|
Switch type |
Managed |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
1 |
|
USB 2.0 ports quantity |
0 |
|
Power |
|
Power over Ethernet (PoE) |
Yes |
|
DC voltage range |
12 V |
|
Input current |
2 A |
|
Power consumption (max) |
12.8 W |
|
Design |
|
Product colour |
White |
|
Reset button |
Yes |
|
LED indicators |
Yes |
|
Antenna |
|
Antenna type |
Internal |
|
Antenna direction type |
Omni-directional |
|
Performance |
|
Built-in processor |
Yes |
|
Processor frequency |
1000 MHz |
|
Weight & dimensions |
|
Width |
160 mm |
|
Depth |
160 mm |
|
Height |
33.2 mm |
|
Weight |
380 g |
|
Packaging data |
|
Package width |
266 mm |
|
Package depth |
165 mm |
|
Package height |
39 mm |
|
Package weight |
570 g |
|
Packaging content |
|
Quantity per pack |
1 pc(s) |
|
Operational conditions |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Storage relative humidity (H-H) |
5 - 95% |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
|
Master (outer) case width |
353 mm |
|
Master (outer) case length |
428 mm |
|
Master (outer) case height |
311 mm |
|
Master (outer) case gross weight |
12.2 kg |
|
Products per master (outer) case |
20 pc(s) |
