Processor |
|
Built-in processor |
No |
|
Motherboard chipset |
AMD B650 |
|
Processor socket |
Socket AM5 |
|
Number of processors supported |
1 |
|
Processor manufacturer |
AMD |
|
Memory |
|
Number of DIMM slots |
4 |
|
Supported memory types |
DDR5-SDRAM |
|
Buffered memory type |
Unregistered (unbuffered) |
|
Maximum UDIMM memory |
32 GB |
|
Supported UDIMM clock speeds |
5200 MHz |
|
Memory form factor |
288-pin DIMM |
|
Memory voltage |
1.1 V |
|
Storage |
|
Number of storage drives supported |
4 |
|
Hot-swap HDD bays |
Yes |
|
Number of 3.5" bays |
4 |
|
Storage drive sizes supported |
3.5" |
|
Ports & interfaces |
|
USB 2.0 ports quantity |
0 |
|
Ethernet LAN (RJ-45) ports |
4 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
|
IPMI LAN (RJ-45) port |
Yes |
|
VGA (D-Sub) ports quantity |
1 |
|
COM ports quantity |
1 |
|
Expansion slots |
|
PCI Express x16 (Gen 4.x) slots |
1 |
|
BIOS |
|
BIOS type |
UEFI AMI |
|
BIOS memory size |
256 Mbit |
|
ACPI version |
6.4 |
|
System Management BIOS (SMBIOS) version |
3.5 |
|
Plug and Play |
Yes |
|
Design |
|
Chassis type |
Rack (1U) |
|
Number of fans |
40 fan(s) |
|
Hot-swap fan module |
Yes |
|
Power |
|
Power supply |
450 W |
|
Number of main power supplies |
1 |
|
Redundant power supply (RPS) support |
Yes |
|
Number of redundant power supplies supported |
1 |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50 - 60 Hz |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 35 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Storage relative humidity (H-H) |
20 - 90% |
|
Weight & dimensions |
|
Width |
438 mm |
|
Depth |
533.4 mm |
|
Height |
44.4 mm |
