Processor |
|
Built-in processor |
No |
|
Motherboard chipset |
AMD SoC |
|
Processor socket |
LGA 6096 |
|
Number of processors supported |
2 |
|
Processor manufacturer |
AMD |
|
Memory |
|
Number of DIMM slots |
24 |
|
Supported memory types |
DDR5-SDRAM |
|
Supported RDIMM clock speeds |
4800 MHz |
|
Memory voltage |
1.1 V |
|
Storage |
|
Number of storage drives supported |
28 |
|
Hot-swap HDD bays |
Yes |
|
Number of 2.5" bays |
26 |
|
Storage drive sizes supported |
2.5,M.2 |
|
Supported storage drive types |
HDD & SSD |
|
Supported storage drive interfaces |
PCI Express |
|
SSD form factor |
M.2 |
|
Graphics |
|
Discrete graphics card model |
Not available |
|
On-board graphics card model |
Aspeed AST2600 |
|
On-board graphics card memory |
512 MB |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet interface type |
Gigabit Ethernet |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
LAN controller |
Intel® I350 |
|
Ports & interfaces |
|
USB 2.0 ports quantity |
1 |
|
Ethernet LAN (RJ-45) ports |
2 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
|
IPMI LAN (RJ-45) port |
Yes |
|
VGA (D-Sub) ports quantity |
2 |
|
COM ports quantity |
1 |
|
Expansion slots |
|
PCI Express slots version |
3.0, 5.0 |
|
Features |
|
Optical drive type |
No |
|
PC health monitoring |
Fan, Temperature, Voltage |
|
Backplanes support |
Yes |
|
BIOS |
|
BIOS type |
UEFI AMI |
|
ACPI version |
6.4 |
|
System Management BIOS (SMBIOS) version |
3.5 |
|
Plug and Play |
Yes |
|
Design |
|
Chassis type |
Rack (2U) |
|
Product colour |
Black, Grey |
|
LED indicators |
HDD, LAN, Power, System, Unit Identification (UID) |
|
Reset button |
Yes |
|
Cooling type |
Active |
|
Number of fans |
6 fan(s) |
|
Hot-swap fan module |
Yes |
|
Number of hot-swap fan modules |
6 |
|
Power |
|
Power supply |
1000 W |
|
Number of main power supplies |
2 |
|
AC input voltage |
220 - 240 V |
|
AC input frequency |
50/60 Hz |
|
80 PLUS certification |
80 PLUS Titanium |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 35 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
20 - 90% |
|
Weight & dimensions |
|
Width |
438 mm |
|
Depth |
770 mm |
|
Height |
86.4 mm |
