Processor |
|
Motherboard chipset |
AMD SoC |
|
Processor socket |
LGA 6096 |
|
Number of processors supported |
1 |
|
Compatible processor series |
AMD EPYC 9004 |
|
Memory |
|
Number of DIMM slots |
24 |
|
Supported memory types |
DDR5-SDRAM |
|
Supported RDIMM clock speeds |
3600,4000,4800 MHz |
|
Memory form factor |
288-pin DIMM |
|
Memory voltage |
1.1 V |
|
Storage |
|
Number of storage drives supported |
14 |
|
Hot-swap HDD bays |
Yes |
|
Number of 2.5" bays |
12 |
|
Supported storage drive types |
HDD & SSD |
|
Supported storage drive interfaces |
PCI Express, Serial ATA III |
|
Graphics |
|
On-board graphics card model |
Aspeed AST2600 |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet interface type |
10 Gigabit Ethernet, Gigabit Ethernet |
|
LAN controller |
Broadcom BCM57416, Intel I210 |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
4 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
|
IPMI LAN (RJ-45) port |
Yes |
|
VGA (D-Sub) ports quantity |
1 |
|
Expansion slots |
|
PCI Express x16 (Gen 5.x) slots |
2 |
|
Features |
|
PC health monitoring |
Voltage, Fan, Temperature |
|
BIOS |
|
BIOS type |
UEFI AMI |
|
BIOS memory size |
256 Mbit |
|
ACPI version |
6.4 |
|
System Management BIOS (SMBIOS) version |
3.5 |
|
Design |
|
Chassis type |
Rack (1U) |
|
Product colour |
Grey |
|
LED indicators |
LAN, Power, System |
|
On/off switch |
Yes |
|
Reset button |
Yes |
|
Cooling type |
Active |
|
Number of fans |
6 fan(s) |
|
Hot-swap fan module |
Yes |
|
Power |
|
Power supply |
1000 W |
|
Number of main power supplies |
2 |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50/60 Hz |
|
80 PLUS certification |
80 PLUS Platinum |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 35 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Storage relative humidity (H-H) |
20 - 90% |
|
Weight & dimensions |
|
Width |
676.5 mm |
|
Depth |
438 mm |
|
Height |
43.4 mm |
